China Rough Terrain Crane, 30 Ton Compact Crane with Cummins Engine

Sinoway Industrial (Shanghai) Co., Ltd.
  • Certification:ISO9001
  • Condition:New
  • Operation Form:Cabin
  • Maximum Lifting Height:>40m
  • Maximum Lifting Weight:20-50t
  • Travel Speed:40 Km,H

Base Info

  • Model NO.:SWORC300
  • Base Boom:10 M
  • Boom Elevating Time:75 S
  • Boom Extending Time:75 S
  • Tyre Size:16-25,28pr
  • Transport Package:Nude
  • Specification:operating weight 35 ton
  • Trademark:SINOWAY
  • Origin:China
  • HS Code:84292090
  • Production Capacity:100 PCS , Year

Description

Basic Info.

Model NO. SWORC300 Base Boom 10 M Boom Elevating Time 75 S Boom Extending Time 75 S Tyre Size 16-25,28pr Transport Package Nude Specification operating weight 35 ton Trademark SINOWAY Origin China HS Code 84292090 Production Capacity 100 PCS / Year

Product Description

SINOWAY SWORC300 Off Road Crane Main Features

Cummins engine, 169 Kw, Four section boom, Single-cylinder plus rops telescopicing mechanism is for synchronous telescoping. Winch is driven by hydraulic motor, with build-in planetary gear reducer, normally closed brake and anti-winding wire rope equipped. main and auxiliary hoist system can be operated separately. Main hoist system: single line pull is 31 KN and rope length is 160 m. Auxiliary hoist system: single line pull is 31 KN and rope length is 95 m.

Equipped with German ZF tranmission with F6 & R3 shift, Two operation modes: Automatic and manual. Axles are adoped Meritor for RT crane. Both front and rear axle are drived, they have heavy load-bearing capacity and high reliability, and are easy to maintain. Both front axle and rear axle are consist of plate spring and hydraulic cylinder. When the vehicle travels, the plate spring has the function of attenuating vibration.The cylinder is along with the axle motion. When the vhicle lifts weight on rubber, all cylinders are locked and the suspension stste is rigid, so as to satify the application. Brakeing system for service is with double-circuit full hydraulic disc brake.acyion on all wheels. Parking brake is spring-loaded brake, hydraulic-released independent disc brake, acting on front axles.
China Rough Terrain Crane, 30 Ton Compact Crane with Cummins Engine
Engine
ModelCummins
TypeElectronically controlled,high pressure common rail diesel engine
Rated power169KW
Rated speed2500rpm
Displacement6.7L
Crane Parameters
Max. total rated lifting load30t×3m
Boom9.18~27.78m
Fully extended boom+jib27.78+7.2m (one-section,angle 0°,30°)
Base boom10m
Main winch80m/min
Auxiliary winch80m/min
Boom angle3°~80°
Boom elevating time75s
Boom extending time75s
Slewing speed2r/min
Turning radius at swing table tail3525mm
hydraulic System
Hydraulic pump63/50,32/08 dual geared pump
Lifting deviceAxial piston hydraulic motor
Slewing deviceAxial piston hydraulic motor
Hydraulic ram capacity400L
Equipments and Structure
Boom profileFour-section boom of octagon cross section
Jib profileOne-section truss (inclination 0°,30°)
Boom extending deviceOne-section telescopic cylinder and rope
Boom elevating deviceFront-mounted single cylinder elevation
Lifting deviceIsolated main and auxiliary lifting devices,plantary reducer driven by hydraulic motor
Slewing deviceFour point contact ball bearing
Outrigger device
TypeH-shaped hydraulic outrigger with an option of both hand and electric control
Outrigger span6085x6500mm (longitudinal+lateral)
Steel wire rope of main winchΦ14~150m
Steel wire rope of auxiliary winchΦ14~90m
Performance Specification
Max.speed40km/h
Grade ability55%
Four wheel steering radius5.1m
Min.turning radius of jib nose9.25m
Undercarriage and Structure
Drive type4×4
Torque converterPlanetary hydrodynamic
Torque converter typeElectric shift, planetary structure gear-box
Transmission type4 forward & 3 reverse
Front axleSteering drive axle
Rear axleSteering drive axle
SuspensionRigid front axle, swing rear axle, hydraulic locking cylinder, electric control
Service brakeAir control, shoe brake
Parking brakeAir control, Air spring brake
Tyre size16-25,28PR
Fuel tank capacity310L
Dimension and weight
Overall length11750mm
Overall width2980mm
Overall height3600mm
Wheel base3600mm
Front tread2500mm
Rear tread2500mm
Overall weight29500kg
Front axle weight14430kg
Raer axle weight15070kg
China Rough Terrain Crane, 30 Ton Compact Crane with Cummins Engine
Sinoway treat Service as a significant segment in our value chain. All of our service-related businesses-aftermarket parts, technical support, training, OEM Solutions are based on offering more professional service, extending the life of each machine we delivered.

For special key projects and VIP customers, Sinoway offer on-site field service for a certain period, to allow the team of our users with a better understanding on the operating and maintenance, to help training the service team of their own, or give a proposal on the maintenance solutions according to the special operating environment. With the field service, we are confident to enable our machinery reduce the downtime at maximum and help our clients fulfill the project smoothly and on time.
ConditionBrand New
WarrantyOne year or 2000 working hours, whichever comes earlier.
Shipment TermsFOB, CFR, CIF, CIP DAF
