• Model NO.：CLW5741xe
• Type：Straight Arm
• Chassis：HOWO
• Gearbox：6 Forward & 1 Reverse Gear
• Working Radius：8.6 M
• Rotation Angle：360 Degree All Rotation
• Logo：as Per Customer′s Request
• Engine：168 HP
• Warranty：1 Year
• Crane Weight：5000 Kg
• Max Lifting Height：12m
• Installation Space：2280-5100mm
• Crane：5ton
• Max. Lifting Capacity：8000 Kg
• Transport Package：Naked, Waxed, Bulk Ship, RO-RO
• Specification：8215x2500x3850 mm
• Trademark：CLW
• Origin：Suizhou, China
• HS Code：8705909090
• Production Capacity：500 Unit,Month

Chassis SpecificationItem No.ParametersChassis BrandHOWO Overall Dimension8215X2500X3850mmGross Vehicle Weight15795  kgCurb Weight8450  kgLoading Weight5805  KgFront/rear  axle loading capacity5000/7200kgWheel Base4500 mmCabinSingle, Left Hand Driving, 2 Passenger AllowedEngineTypeDiesel Engine Engine horsepowerCummins 168HP EURO IIGearboxManual ,  6 Forward & 1 Reverse GearBrake SystemAir BrakeSteering GearPower AssistantTire9.00-20, 6 Pieces with 1 SpareMax Driving Speed90 km/hCargo compartmentMaterialQ235Dimension5070X2400X600mmThickness3mm for side /4 mm for the bottomTechnical parameter of craneCrane  Model5 Ton 3 Arms Telescopic Boom CraneCrane Weight2120 kgMax. Lifting capacity5000 kgMax lifting height12 MWorking radius8.6 MOutrigger span2280-5100mmRotation angle360°All rotationOptional1. Seat
2. Hydraulic Lift system
3. Landing LegRemarks1. Color is optional
2.Customized LOGO painting as per customer request
