35ton Material Handling Excavator Machine for Scrap Metal Recycling

Sinoway Industrial (Shanghai) Co., Ltd.
  • Certification:ISO9001
  • Condition:New
  • Operation Form:Cabin
  • Maximum Lifting Height:15-20m
  • Maximum Lifting Weight:<20t
  • Max. Trave Speed:15km,H

Base Info

  • Model NO.:SWMH350K
  • Max. Working Radius:14 M
  • Max. Hoisting Moment:525kn.M
  • Max. Lifting Height:15 M
  • Engine Power:360HP
  • Warranty:1 Year
  • Transport Package:Nude
  • Specification:ISO
  • Trademark:Sinoway
  • Origin:China
  • HS Code:84314990
  • Production Capacity:100 PCS , Year

Description

PowerElectrical motor110kwRated speed1480rpmMax. swing speed (electrical motor)5r/minDiesel engine154kwRated speed2200rpmMax. swing speed (diesel engine)8r/minFuel tank capacity440LMain Technical SpecificationMax. lifting capacity@Min. working radius13000kgMax. lifting capacity@Max. working radius2000kgMin. working radius4000mmMax. working radius14000mmMax. lifting moment52.5t.mMax. swing torque107KN.mBoom length8000mmArm length6000mmMain luffing time (Max. speed)Fall boom (electrical / diesel)≤17s/≤11sRise boom (electrical / diesel)≤21s/≤11sAuxiliary luffing time (Max. speed)Fall boom (electrical / diesel)≤20s/≤11sRise boom (electrical / diesel)≤9s/≤6sOutriggerFall stretching (electrical / diesel)≤16s/≤11sFall retracting (electrical / diesel)≤12s/≤10sOutrigger distanceLengthways4500mmTransversal4200mmTravelling SystemMax. travelling speed15km/hMin. turning radius7.6mMax. gradeability18%Min. ground clearance250mmMax. traction force109kNApproach angle15.0°Departure angle15.0°Braking distance (speed: 15km/h)≤6.5mOperating weight35000kg (including clam shell)DimensionA. Overall length11000mmB. Overall width3500mmC. Overall height3190mmD. Wheelbase3200mmE. Max. lifting height of cab5900mmF. Rear-end length/slewing radius3650mmG. Counterweight clearance1430mmH. Upper-structure width2940mm
Sinoway treat Service as a significant segment in our value chain. All of our service-related businesses-aftermarket parts, technical support, training, OEM Solutions are based on offering more professional service, extending the life of each machine we delivered.
For special key projects and VIP customers, Sinoway offer on-site field service for a certain period, to allow the team of our users with a better understanding on the operating and maintenance, to help training the service team of their own, or give a proposal on the maintenance solutions according to the special operating environment. With the field service, we are confident to enable our machinery reduce the downtime at maximum and help our clients fulfill the project smoothly and on time.
ConditionBrand New
WarrantyOne year or 2000 working hours, whichever comes earlier.
Shipment TermsFOB, CFR, CIF, CIP DAF
