• Model NO.：MINI
• Operation Form：Pendent Button Control , Remote Control
• Type：Common Gantry Crane
• Main Girder Form：Single Girder
• Product Name：Mini Gantry Crane
• Power Source：220V,380V,415V or on Request
• Color：Industrial Yellow,Red or on Request
• Girder Type：Box Type
• Insulation：F
• Moving Type：Wheels Running
• Application：Widely Applied for Indoor and Outdoor Workplaces
• Aftersale Service：Engineer Overseas Service Available
• Electric Parts：Chint
• Hoist Type：Rope Hoist , Chain Hoist on Request
• Work Duty：A3-A5
• Lift Capacity：on Request
• Motor：Gear Motor
• Transport Package：Standard Package for Ocean Shipping or Railway
• Specification：Materials: Q235B,Q345B
• Trademark：Mingdao
• Origin：China
• HS Code：8426193000
• Production Capacity：1000sets, Year

Loading capacity0.25 ~ 6.5tLifting height3 ~ 10 m or customizedLifting speed

Single speed: 3~ 8 m/min; or customized

Variable frequency speed: 1 ~ 20 m/min; or customized

Span3~10 mLifting mechanismHoist trolleyWorking classA2 ~ A3Working temperature-20 ~ 40 ºCPower supplyAC-3Phase-220//230380/400/415/440V-50/60HzControl voltageDC-24 / 36VMotor protection classIP54 IP55 IP65Control wayGround handle control(Push button),wireless remote controlSafety deviceBuffer, current overload protection,overload device,power failure protectionApplication areaFactory,workshop,warehouse,power station,logistic,etc.Painting colorYellow,Red or Customized





Main Parameters ListCrane Traveling MechanismTraveling Speed(m/min)20MotorTypeCone Squirrel-cagePower(kw)ZDY21-4/0.8X2Hoist Lifting Mechanism and Traveling MechanismElectric Hoist ModelCD1,MD1,HCLifting Speed(m/min)8 0.8/8Span(m)12-30Lifting Capacity(t)3-32TonLifting Height(m)6,9Traveling Speed(m/min)20MotorCone Squirrel-cageWork DutyIntermediate Jc=25%Power Supply380V 50HZ 3PWheel DiameterΦ270 Φ400ReducerZSC650 ,LD




CUSTOMER VISITING FACTORY



CUSTOMER FEEDBACK

Certificate:


FAQ

Q1. Can the cranes be customized?
Yes,every customer's working condition is different, all of our products can be customized depend on customers' requirements. Please give us the information as clear as you can, so we can give our best design to suit for your demands.

Q2. How many operation methods for my selections?
We provide pendent controller with push button control type, remote control type or cabin control type.Please tell us what kind of operation way you need.

Q3. I have low headroom in my workshop, is it possible to install a crane in it?
We have special products for low headroom workshop, our engineer can give the best design according to your dimensions.

Q4. Do you supply lift tools?
Yes, we can provide any kind of lifting tools such as hook, electromagnetic, grab bucket etc...

Q5: In order to offer the most suitable design solution for you, it will be great helpful if you can offer us the following information to us:
1. Lifting capacity.

2. Span length.(rail center to rail center)

3. Lifting height.(hook center to ground)

4. Have you installed the rails? Do you need us to supply the rails? How long is it? 5. Power supply: Voltage.

6. Working condition: what kind of material to lift? temperature?

7. It would be much better if it is possible for you to offer the drawing photo of your workshop.
