Zoomlion Ztc800V532 80 Ton Mobile Crane Telescopic Boom Truck Crane

Sinomada Heavy Industry (Changsha) Co., Ltd.
  • Certification：CE, ISO9001
  • Condition：New
  • Maximum Lifting Height：30-40m
  • Maximum Lifting Weight：>16t
  • Shaft Number：4
  • Crane Jib：Two-Arm

Base Info

  • Model NO.：ZTC800V532
  • Type：Folding
  • Max. Rated Lifting Capacity：80000kg
  • Max. Lifting Height of Jib：46.58m
  • Boom Demrricking up Time：25s
  • Outrigger Spread：5.40m
  • Transport Package：Comply with Export Packaging Requirements for Min
  • Specification：14500*2800*3850 mm
  • Trademark：ZOOMLION
  • Origin：China
  • HS Code：84262000
  • Production Capacity：100 Units Per Month

Description

Dimensions

Overall dimensions (L×W×H) mm

14500×2800×3850



Longitudinal distance between outriggers                m

6.05



Transversal distance between outriggers                 m

Completely extended:7.8



Tail slewing radius                                                   mm

4200



Main boom length                                                     m

12.1 - 47.0



Boom angle                                                               °

-2 - 80



Jib length                                                                  m

9.5, 16.0



Offset                                                                          °

0, 15, 30






Pictures

Zoomlion Ztc800V532 80 Ton Mobile Crane Telescopic Boom Truck Crane
Zoomlion Ztc800V532 80 Ton Mobile Crane Telescopic Boom Truck Crane
Zoomlion Ztc800V532 80 Ton Mobile Crane Telescopic Boom Truck Crane
