Brand New Material Grabbing Crane Material Grabbing Handler

Sinoway Industrial (Shanghai) Co., Ltd.
  • Certification:ISO9001, ISO14001
  • Condition:New
  • Application:Workshop, Warehouse, Coal Stack, Port, Wharf, Construction Site, Mine
  • Anchor:Removable
  • Structure:Lattice
  • Material:Steel

Base Info

  • Model NO.:swmh120l
  • Type:Cantilever
  • Working Radius:10.2 M
  • Max. Lifting Height:11.3 M
  • Max. Travel Speed:15km,H
  • Max. Hoisting Moment:300kn.M
  • Warranty:One Year
  • Operating Weight:40 Ton
  • Transport Package:Nude
  • Specification:ISO
  • Trademark:Sinoway
  • Origin:China
  • HS Code:84294990
  • Production Capacity:500 PCS , Year

Description

Basic Info.

Model NO. swmh120l Type Cantilever Working Radius 10.2 M Max. Lifting Height 11.3 M Max. Travel Speed 15km/H Max. Hoisting Moment 300kn.M Warranty One Year Operating Weight 40 Ton Transport Package Nude Specification ISO Trademark Sinoway Origin China HS Code 84294990 Production Capacity 500 PCS / Year

Product Description

The main Feature of SWMH350L Material Handlers
1-Dual engine ( Electric motor + Diesel engine) more environmental protection;
2-Electric operation has over-current and heat leakage protection device;
3-Utomatic identification of phase sequence to prevent reverse rotation of oil pump;
4-Hydraulic system power-off, oil self-locking protection device;
5-Multiple compound movements during operation to improve efficiency;
6-The hydraulic system is equipped with air-cooled radiator;
7-The gripper can rotate and change direction automatically 360 degrees;
8-When electric operation is carried out in the upper control room, there is a dual-purpose air conditioner for heating and cooling;
9- Hydraulic Cabin elevatied.Brand New Material Grabbing Crane Material Grabbing Handler
Dimensions
Overall length7604mm
Overall height4021mm
Overall width3435mm
Wheelbase3600mm
The maximum lifting height of driving cab5721mm
Tail slewing radius4175mm
Gap between rotary table and ground1782mm
Width of platform627mm
Power
Engine162kw
Electric Motor110kw
Fuel tank295L
Walking System
Walking speed15km/h
Max.tranction force110KN
Gradeability10%
Hydraulic System
Max.flow2*214L/min
Max.working pressure28Mpa
Hydraulic oil tank420L
Pilot pressure3.6Mpa
Main Performance Parameters
Total weight40t
Max.Lifting moment126t.m
Max.swing speed3.7r/min
Max.swing torque51KN.m
