• Model NO.：LDA
• Type：Single Girder Crane
• Capacity：1-32t
• Power Source：Electric
• Sling Type：Wire Rope
• Application：Workshop Usage
• Power Supply：380V,400,415,440V 50,60Hz 3pH
• Transport Package：Strong Wooden Box
• Specification：LD
• Trademark：shengqi
• Origin：China
• HS Code：84253100
• Production Capacity：20000PC,Year

Basic Info.

Model NO. LDA Type Single Girder Crane Capacity 1-32t Power Source Electric Sling Type Wire Rope Application Workshop Usage Power Supply 380V/400/415/440V 50/60Hz 3pH Transport Package Strong Wooden Box Specification LD Trademark shengqi Origin China HS Code 84253100 Production Capacity 20000PC/Year

Product Description

Single Girder Overhead Crane1. Capacity: 1-32t
2. Span: 5-35m
3. Lifting height: 6-100m
4. Certificate: ISO 9001

1. Introduction

The 1 LDA type single girder electric overhead crane is the most commen crane. It has the advantage of light deadweight, little material, low price, easy control and convenient amending.
LD type single girder electric overhead crane working class A3-A5, working ambient is from -25C to +40C.
LD type single beam electric bridge crane was recommended by WTO and apply to China standard JB/T1306-94.
LD crane has two operational methods- pendant/wireless radio or cabin (open or closed type).

LD type single girder electric crane can be divided into three parts as follow:
1. Steel structure inclueds main beam and end truck
2. Lift equipment, CD/MD or chain hoist. LD crane could have one or two speed.
3. Crane traveling mechanism: Two end carriages with wheels driven by electric motor.







1. The quality of the main girder decides use age and use cost of the crane. "shengqi" consummately adopt European most advanced design and manufacture craft of the main girder. Mail girder wear well , not only let user ease use, but also low maintenance cost.

2. The up camber curve of main girder adopt optimize 4 times curve, ensure traveling have no upgrade resistance when full loading. Overcome the disfigurement of traveling motor overload traveling and trolley slide traveling.

3. End carriage is box girder, and the connection between end carriage and main girder adopt high strength bolt, in order to transport conveniently.

4. Optimize structure design, bearing layout reasonable , bear horizontal force, improve use age of the bearing.

5. The connections of every mechanical part are gears, in order to achieve simple installation and convenient maintenance. The drive wheel group and driven wheel group are all supported on crescent bearing box , convenient for disassembly and adjust.

Cause this is a kind of customized product,please provide us with the following information:
1. Lifting capacity.
2. Span length. (rail center to rail center)
3. Lifting height. (hook center to ground)
4. Do you need bus bar, rail from us?
5. Local power supply 380V 50Hz 3P?
6. Working condition: What goods to lift?
7. Drawings of working place would be appreciated.
