• Model NO.：ZTC600V532
• Type：Folding
• Max. Rated Lifting Capacity：60000kg
• Max. Lifting Height of Jib：46.58m
• Boom Demrricking up Time：25s
• Outrigger Spread：5.40m
• Transport Package：Comply with Export Packaging Requirements for Min
• Specification：14500*2800*3850 mm
• Trademark：ZOOMLION
• Origin：China
• HS Code：84262000
• Production Capacity：100 Units Per Month

ItemUnitValueRemarksWorking    performanceMax.    rated lifting capacitykg60000 Max.    load moment of basic boomkN.m2033 Max.    load moment of main boom(fully extended)kN.m1192 Max.    load moment of basic boomm12.8 Max.    lifting height of main boomm45.7These    parameters do not include deflection of main boom and jibMax.    lifting height of jibm61.5Working    speeds            Max.    hoist rope speed(Main winch)m/min125At    the 4th  layerMax.    hoist rope speed(Auxiliary winch)m/min125At    the 4nd   layerBoom    demrricking up times45 Boom    telescoping out times95 Slewing  speedr/min0    -2.2 Driving    parametersMax.    driving  speedkm/h85 Max.    gradeability%47 Turning    diameterm≤23 Min.  ground clearancemm285 Oil    consumption per hundred kilometersL43 MassDeadweight    in driving conditionkg42000 Complete    vehicle kerb masskg41805 Front    axle loadkg16000 Rear    axle loadkg26000 DimensionsOverall    dimensions(L×W×H)mm13950×2800×3750 Outrigger    spread(L)m5.92 Outrigger    spread(W)mFully    extended: 7.1 Tail    slewing radiusmm3930 Main    boom lengthm11.6    - 45.0 Boom    angle°-2    - 80 jib    lengthm9.5,16.0 Offset°0,15,30
