• Model NO.：ZCC5000
• Central Counteweight：32ton
• Rear Counterweight：83.7ton
• Transport Package：Containner
• Specification：8000 *9800*1350 mm
• Trademark：ZOOMLION
• Origin：China

Overview Product Description

EFFICIENT, QUICK AND SAFETY

The mechanism operating speed up 20%, and the speed of each mechanism don't slow down

while operating 2 functions simultaneously;

Time of erecting the whole crane is less than 6 hours;

Omni-directional real-time LMI and monitoring system, to ensure safety operation.



CONVENIENT, COMFORTABLE AND INTELLIGENCE

The max. Single transport weight is 30.5t, transport width is 3m;

Omni-directional vehicle information platform, real time monitoring equipment operation,

The IOT intelligent interaction system make the mobile service come true.

Full view cabin, buttons and switches are all within reach,

all-around air conditioner form a comfortable operating space.

ItemUnitValueRemarksMax. lifting capacity on heavy duty boom(S)/RadiusWithout D and B       t450Length of heavy duth boom(S)Without D and B           m24-90With D and B   m36-96Length of light duty boom(SL)Without D and B            m48-108With D and B   m78-126Dead weight of crane with basis boomm370Length of luffing jib(W)m28-84Max.lifting capacity on luffing jibWithout D and B   t190Boom angle when luffing jib is usedMax. length of heavy duty boom withWithout D and B           m60+72With D and B   m84+84SLHS boomMain boom     m84-108Wind plant jib   m7Max.lifting capacity    t126Single rope speed of winchesHoisting winch 1m/min0-137Hoisting winch 20-137Main boom derricking winch0-50Luffing jib derricking winch0-123Superlift derricking winch0-143Hoisting winch 30-109Slewing speedrpm

0-1.0

Traveling speedkm/h0-1.0Gradeability%30Ground pressureMpa0.139Transport dimensions of basic machinemm12180×3345Max.transport weight of single piece 48.6EngineRated power / rotational    speedkW/r/min360/1800Output torque /rotational    speedNm/r/min2200/1300Exhaust emission EU Stufe 3ADistance between track    center × crawler contact length × crawler widthmm8000 ×9800Packaging & Shipping
