• Model NO.：MG
• Main Girder Form：Double Girder
• Corlor：Industrial Red and Yellow
• Control Method：Room Control or Remote Control
• Lifting Speed：8,0.8 7,0.7 3.5,0.35
• Power：Customization
• Work Duty：A3-A5
• Traveling Speed：20m,Min
• Power Supply：380V,50Hz,3p, Can Be Customized
• Electrical System Brand：Siemens,Schneider,Chint
• Affiliate Documents：English Operation Manual, Wiring Diagram
• Stepless Speed Control：Available (Variable Frequency Control)
• Transport Package：40′ Container
• Specification：A3-A5
• Trademark：LYFOO
• Origin：Henan, China
• HS Code：7201500010
• Production Capacity：50 Sets,Month

Capacity/t10/3.2 16/3.2 20/5 32/5 50/10 80/20 100/50 125/30 160/30Span/m22  26  30  35  40Power SupplyThree Phrase Alternating Current
Features:
1) Reasonable structure
2) Favorable performance
3) Smooth starting and stopping
4) Safe and reliable traveling
5) Low noise, commodious cabin and good view
6) Convenient maintenance, excellent exchangeability for parts and components
7) Saves electricity

Technical Characteristics:
1) Hard-tooth surface of reducer
2) Steel winding drum
3) Imported rope
4) Converter function of adjustable speed without contact or module
5) Intelligence controlling
6) Trinity drive


Cause this is a customized product, please provide us the following information
Capacity?
Lifting Height? (from hook to the ground)
Span?
Local Power-V-Hz-P?

Remarks:

Testing:  After award of the contact, the crane shall be manufactured, assembled & test at our factory in Henan, China. Before dispatch, the crane would be tested, including 125% static load test &110% dynamic load test. After testing, no accessories crack damage, bridge without permanent deformation, the crane could be delivered in "ready-to-install" condition.

Packing:  For the main beams will be packed by plastic woven cloth. Motor electrical system and accessories (electric pulley, cable, copper core, standard component, etc.) should be packed high quality wooden box.

Delivery:  Within 25 days after receiving deposit.

Validity:   Quotation validity remains in one month after quote made.(in case to the material price & exchange rate fluctuation.)

Payment terms: 30% TT advance payment, 70% TT against copy of B/L.

Warranty: 12 months warranty after installation and commissioning or 18 months after delivering in addition to the human damage factors. Deliver with English user manual, parts manual, product certification and other relevant certificates.
