• Model NO.：SWPTC400
• Type：Cantilever
• Engine Make：Volvo
• Rated Power：250 HP
• Boom Length：19 M
• Max. Travel Speed：15km,H
• Brand：Sinoway
• Lifting Capacity：40 Ton
• Model：Swmh350L
• Warranty：One Year
• Transport Package：Nude
• Specification：ISO
• Trademark：Sinoway
• Origin：China
• HS Code：84294990
• Production Capacity：100 PCS , Year

Main Technical SpecificationEngine makeVOLVORated power185KW/2200rpmTorque1160N.m/1350rpmDrive axleMERITORSteering axleMERITORTyre12.00-20 18PRLift the cable speed75~130m/minRange of time30s (25°~ 75°)Max. Slewing speed3.5rpmMax. Speed15km/hBrake distance3m(10km/h)Gradeability23%Operating weight39t(19m Boom Length)Lifting capacity40tStandard configuration boom length(6 ratio)19mThe longest boom31mMax working radius(31m boom length)26mStandard configuration working radius(19m boom length)18mMinimum working radius4mLifting altitude(31m boom length)28mStandard configuration boom(19 m boom length)16mOverall dimensions(without boom)(A×B×C)7000×3200×3900mmD: Wheelbase3800mmE: Tread2410mmF: Outrigger longitudinal span6200mmG: Outrigger transverse span6200mmH: Max. Boom length28000mmI: Radius of tail turning3560mmMin. Turning radius9300mmOutrigger device TypeH-shaped hydraulic outrigger with an option of both hand and electric controlOutrigger span8400×8200/6000mm (longitudinal+lateral)Steel wire rope of main winchΦ20~220mSteel wire rope of auxiliary winchΦ18~190mPerformance Specification Max.speed33km/hGrade ability60%Min.ground clearance568mmMin.turning radius of jib nose7.5mUndercarriage and Structure Drive type4×4/4×2Steering modeIndependent front axle, steering,small truning radius,crab walk and independent rear axle steeringSuspensionRigid front axle,swing rear axle,hydraulic locking cylinder,electric controlService brakeHydraulic dual circle,disc brakeParking brakeMechanical disc brake,hydraulic releaseFuel tank capacity320LDimension and weight Overall length14900mmOverall width3500mmOverall height3990mmOverall weight76830kgFront axle weight41710kgRaer axle weight35120kgRaer axle weight27650kg
