Zoomlion 25 Tons Mobile Truck Crane Qy25D531r for Sale
Sinomada Heavy Industry (Changsha) Co., Ltd.- Certification：CE, ISO9001
- Condition：New
- Maximum Lifting Height：30-40m
- Maximum Lifting Weight：>16t
- Shaft Number：2
- Crane Jib：Four-Arm
Base Info
- Model NO.：QY25D531R
- Type：Folding
- Max. Traveling Speed：78km,H
- Max. Gradeability：37%
- Min. Turn Radius：11m
- Min. Ground Clearance：220m
- Max. Lifting Height of Jib：47m
- Jib Length：8m
- Transport Package：Nude
- Specification：25t
- Trademark：Zoomlion
- Origin：China
- HS Code：87051091
- Production Capacity：100units,Month
Description
Type
Ser. No.
Item
Unit
Value
Working performance
1
Max. rated lifting weight × working radius
kg.m
25000×3.0
2
Max. lifting torque of basic boom
kN.m
980
3
Max.lifting torque of longest main boom
kN.m
494
4
Max. lifting height of longest main boom
m
39
5
Max. lifting height of jib
m
47
Dimensions
6
Outline dimensions (L×W×H)
mm
12700×2500×3450
7
Distance between outriggers (longitudinal × transversal)
mm
5360×6100
8
Main boom length (completely retracted - completely extended)
m
10.4~39.2
9
Jib length
m
8
10
Main boom angle of elevation
°
-2~80
11
Swing range
360°continuously
Working speed
12
Max.speed of single rope on the drum of main winch
m/min
120
13
Boom extension time
s
80
14
Boom derricking up time
s
40
15
Swing speed
r/min
0~2.2
Mass
16
Complete vehicle kerb mass
kg
31570
17
Front axle load
kg
6900
18
Rear axle load
kg
24800
Traveling
19
Max. traveling speed
km/h
78
20
Max. gradeability
%
37
21
Min. turn radius
m
11
22
Min. ground clearance
mm
220
