Solas Approved Fast Rescue Boat a Frame Davit

ZHENJIANG JUST MARINE IM & EX CO., LTD.
  • Warranty：1 Year
  • Certification：CCS ABS BV Lr
  • Transport Package：Export Standard

Base Info

  • Model NO.：JM 30

Description

Hoisting speed of rescue boat:≥18m/min
Lowering speed of boat (designed): 40~60m/min

Designed conditions: Heel 200 +trim 100

Size of boat fall: 18×19-18-1770, Min. breaking load 180KN Galv.-nontwist type

Hoisting height:     30m
Type of stored power unit:

Motor for pump station                                  Motor for winch

Power: 5.5KW                                                     Power: 11KW

Model: Y132S-4-H                                             Model: YZ160L-6-H

Protection grade: IP56                                     Protection grade: IP56

Insulation class: "F"                                           Insulation class: "F"

Motor with heater

Power source: AC 440V,60Hz, 3 phrases

Self weight:~3500Kg
