| Item | Unit | Value |
|---|
| Working performance | Max. rated lifting capacity | kg | 80000 |
| Max. load moment of basic boom | kN.m | 2575 |
| Max. load moment of main boom(fully extended) | kN.m | 1240 |
| Max. load moment of basic boom | m | 12.2 |
| Max. lifting height of main boom | m | 44.2 |
| Max. lifting height of jib | m | 60.2 |
| Working speeds | Max. hoist rope speed(Main winch) | m/min | ≥135 |
| Max. hoist rope speed(Auxiliary winch) | m/min | ≥110 |
| Boom demrricking up time | s | 57 |
| Boom demrricking up time | s | 107 |
| Slewing speed | r/min | 1.8 |
| Driving | Max. driving speed | km/h | 75 |
| Max. gradeability | % | 37 |
| Turning diameter | m | 24 |
| Min. ground clearance | mm | 280 |
| Oil consumption per hundred kilometers | L | 46 |
| Mass | Deadweight in driving condition | kg | 45000 |
| Complete vehicle kerb mass | kg | 44870 |
| Front axle load | kg | 19000 |
| Rear axle load | kg | 26000 |
| Dimension | Overall dimensions(L×W×H) | mm | 14100×2750×3750 |
| Longitudinal distance between outriggers | m | 6.00 |
| Transversal distance between outriggers | m | For completely extended outriggers: 7.60 m;
For intermediately extended outriggers: 5.04 m |
| Tail slewing radius | mm | 4020 |
| Main boom length | m | 11.6 - 44.0 |
| Main boom angle | ° | -2 - 80 |
| jib length | m | 9.5,16.0 |
| Offset | ° | 0,30 |
