Waste Metal Handling Machine 35 Ton Wheeled Material Handler with Four-Point Stabilizer

Sinoway Industrial (Shanghai) Co., Ltd.
  • Certification：ISO9001, ISO14001
  • Condition：New
  • Operation Form：Cabin
  • Maximum Lifting Height：15-20m
  • Maximum Lifting Weight：<20t
  • Max. Working Radius：14 M

Base Info

  • Model NO.：swmh350k
  • Max. Hoisting Moment：525kn.M
  • Max. Lifting Height：15 M
  • Engine Power：360HP
  • Warranty：1 Year
  • Transport Package：Nude
  • Specification：ISO
  • Trademark：Sinoway
  • Origin：China
  • HS Code：84314990
  • Production Capacity：100 PCS , Year

Description

PowerElectrical motor110kwRated speed1480rpmMax. swing speed (electrical motor)5r/minDiesel engine154kwRated speed2200rpmMax. swing speed (diesel engine)8r/minFuel tank capacity440LMain Technical SpecificationMax. lifting capacity@Min. working radius13000kgMax. lifting capacity@Max. working radius2000kgMin. working radius4000mmMax. working radius14000mmMax. lifting moment52.5t.mMax. swing torque107KN.mBoom length8000mmArm length6000mmMain luffing time (Max. speed)Fall boom (electrical / diesel)≤17s/≤11sRise boom (electrical / diesel)≤21s/≤11sAuxiliary luffing time (Max. speed)Fall boom (electrical / diesel)≤20s/≤11sRise boom (electrical / diesel)≤9s/≤6sOutriggerFall stretching (electrical / diesel)≤16s/≤11sFall retracting (electrical / diesel)≤12s/≤10sOutrigger distanceLengthways4500mmTransversal4200mmTravelling SystemMax. travelling speed15km/hMin. turning radius7.6mMax. gradeability18%Min. ground clearance250mmMax. traction force109kNApproach angle15.0°Departure angle15.0°Braking distance (speed: 15km/h)≤6.5mOperating weight35000kg (including clam shell)DimensionA. Overall length11000mmB. Overall width3500mmC. Overall height3190mmD. Wheelbase3200mmE. Max. lifting height of cab5900mmF. Rear-end length/slewing radius3650mmG. Counterweight clearance1430mmH. Upper-structure width2940mmWaste Metal Handling Machine 35 Ton Wheeled Material Handler with Four-Point Stabilizer
Waste Metal Handling Machine 35 Ton Wheeled Material Handler with Four-Point Stabilizer


Why Choose Us
