XCMG Official 3600 Ton Largest Crawler Crane Xgc88000
Xuzhou Construction Machinery Group Import & Export Co., Ltd.- Rated Loading Capacity：3600t
- Certification：ISO9001
- Condition：New
- Warranty：1 Year
- Rated Lifting Moment：88000 T.M
- Max. Gradeability：30%
Base Info
- Model NO.：XGC88000
- Transport Package：Comply with Export Packaging Requirements
- Trademark：XCMG
- Origin：Jiangsu China
- HS Code：87059091
- Production Capacity：10000,Year
Description
(m)60~120(heavy type)/ 126~144(light type) Boom luffing angle (°) - Fixed jib length (m) - Tower jib length (m) 36~108(optional) Max. dimension of single unit in transport state(L×W×H) (m) 13×3.5×3.4 Fixed jib offset angle (°) - Special jib length (m) 15~33(optional) Speed parameter * Max. single line speed for hoist mechanism (m/min) 60 Max. single line speed for boom luffing mechanism (m/min) 63 Max. single line speed for jib luffing mechanism (m/min) - Max. slewing speed (r/min) 0.024 Max. travel speed (km/h) 0.37 Grade ability (%) 6 Mean ground pressure (MPa) - Max. single line speed for tower jib luffing mechanism (m/min) 70 Max. single line speed for superlift luffing (m/min) - Engine * Model - QSK23 Engine power (kW) 3×641 Mass parameter * Overall crane mass (t) 5350(main hook+60m boom) Max. mass of single unit in transport state (t) 65
