• Model NO.：QY80
• Type：Folding
• Lifting Capacity：85t
• Max.Lifting Height：41.5m
• Overall Dimensions：14680mm*2750*4000mm
• Dead Weight in Travel State：46570kg
• Moving Type：Wheel
• Max.Output Torque：2910.6kn.M
• Transport Package：Roro or Bulk Break Shipment
• Specification：CE
• Trademark：S ANY
• Origin：Huan, China
• HS Code：87051091
• Production Capacity：100 Units Per Month

Basic Info.

Model NO. QY80 Type Folding Lifting Capacity 85t Max.Lifting Height 41.5m Overall Dimensions 14680mm*2750*4000mm Dead Weight in Travel State 46570kg Moving Type Wheel Max.Output Torque 2910.6kn.M Transport Package Roro or Bulk Break Shipment Specification CE Trademark S ANY Origin Huan, China HS Code 87051091 Production Capacity 100 Units Per Month

Product Description

S ANY 85 ton truck mobile crane STC850 new mobile crane

S ANY STC850 truck crane boasts powerful lifting capacity. Its five-section boom is made of high strength steel structure and optimized U-shaped cross section with max.lifting capacity of 85t, full-extended boom length of 47m, jib length of 17.5m, max.lifting height including jib of 64.7m, reduce weight and improve safety significantly.
Powerful Lifting Capacity
The 85 ton truck crane is equipped with five-section boom of high strength steel structure and optimized U-shaped cross section with max.lifting capacity of 85t, full-extended boom length of 47m, jib length of 17.5m, max.lifting height including jib of 64.7m, reduce weight and improve safety significantly.
Jib mounting angles are 0°, 15°, and 30°, which ensure fast and convenient change-over between different operating conditions so as to improve working efficiency of the machine.
Efficient & Unique Hydraulic System
Load feedback and constant power control is applied to provide strong lifting capacity and good micro-mobility. Unique steering buffer design is adopted to ensure stable braking operation.
Excellent Traveling Performance
Double-axle drive is used to provide good trafficability and comfortableness under complex road condition; all-wheel steering design with the third and fourth axles as auxiliary steering axle features small turning radius;
The pressure of outriggers could be displayed in control cab; engine has the multimode power output function, which reduces power consumption; the use of tipping over early-warning technology provides high stable and safe operation.
Intelligent Electronic Control
Self-developed controller SYMC special for engineering machinery is configured. The adoption of CAN-bus full-digital network control technology ensures stable control signal, simple harness, and high reliability. Timely feedback of data information can achieve the monitoring of the overall working status in real time.
The Load Moment Limiter
Equipped with the comprehensive intelligent protection system is used with accuracy within 3%. The adoption of comprehensive logic and interlock control system ensures more safe and reliable operation.


Parameter -- S ANY Truck Crane STC850

 apacity
Max. lifting capacity
85t
Dimensions
Overall length
14680mm
Overall width
2750mm
Overall height
4000mm
Axles
4
Axle distance-1,2
1520mm
Axle distance-2,3
4650mm
Axle distance-3,4
1500mm
Weight
Overall weight
46570kg
Front axle load
21600kg
Rear axle load
24970kg
Engine
Model
Cummins
Rated power
275kw/2100rpm
Rated torque
1550N·m/1100~1400rpm
Emission standard
EuroIII
Traveling
Max. traveling speed
80 km/h
Min.turning radius
10 m
Min.turning radius of boom head
12.9m
Drive train
8 × 4
Min. ground clearance
300mm
Approach angle
21 °
Departure angle
21 °
Max. gradeability
38%
Fuel consumption per 100km
≤ 50L
Main Performance
Temperature range
- 30 ºC~ + 60 ºC
Min.lifting radius
3m
Tail swing radius of superstructure
4.339m
Boom section
5
Boom shape
U-shaped
Max. lifting moment-Base boom
2910.6kN·m
Max. lifting moment-Full-extend boom
1411.2kN·m
Max. lifting moment-Full-extend boom+jib
683kN·m
Length-Base boom
12.2m
Length-Full-extend boom
47m
Length-Full-extend boom+jib
64.5m
Outrigger span(Longitudinal/Transversal)
6.18×7.8m
Jib offset
0 ° 15 ° 30 °
Working Speed
Max. single rope lifting speed of main winch(no load)
130 m/min
Max. single rope lifting speed of auxiliary winch(no load)
130 m/min
Full extend/retract time of boom
150 / 150s
Full raise/lower time of boom
70 / 90s
Swing speed
2 r/min
Aircondition
HVAC in up cab
Cooling / Heating
HVAC in low cab
Cooling / Heating
