Acntruck Crawler Crane Quy100 100t Mobile Machine for Construction Works
Acntruck Automobile Sales (Shanghai) Co., Ltd.- Max. Lifting Height：100m
- Rated Loading Capacity：15000kg
- Certification：CE, RoHS
- Condition：New
- Hydraulic Cylinder Brand：China
- Unique Selling Point：High Operating Efficiency
Base Info
- Model NO.：QUY100
- Transport Package：Nude Package, Attached Parts and Tools Into Standa
- Specification：10.3X2.5X3.9
- Trademark：ZOOM-LION
- Origin：China
- HS Code：3005909000
- Production Capacity：1000
Description
Item
Value
Remarks
Max. lifting capacity/Radius t/m
100/5
Deadweight with basic boom t
110
Main boom length m
19~73
Fixed jib length m
13~31
Max. lifting capacity of fixed jib t
12
Offset angle of fixed jib°
10,30
Max. length of main boom with fixed jib m
55+31,55+25,61+19
Luffing jib length m
24~45
Max. lifting capacity of luffing jib t
24
Main boom angle under luffing jib working condition°
65,75,85
Max. length of main boom with luffing jib m
46+45,49+42
Max. speed of single rope on drum
Main winch m/min
110
The 4th rope layer
Auxiliary winch m/min
110
The 4th rope layer
Derricking winch m/min
45
The 4th rope layer
Slewing speed rpm
0~2.2
Traveling speed km/h
0~1.3
Gradeability%
30%
Ground pressure MPa
0.1
Overall dimensions (L×W×H)mm
9500×6000×3500
Without mast and boom frame
Engine
Rated power/ rotational speed kW/rpm
209/2100
Max. output torque/ rotational speed Nm/rpm
1425/1400
Emission standard
U.S. EPA Tier
