| Item | Unit | Value |
| Working performance | Max. rated lifting capacity | kg | 25000 |
| Max. load moment of basic boom | kN.m | 950 |
| Max. load moment of main boom(fully extended) | kN.m | 525 |
| Max. lifting height of main boom | m | 38.7 |
| Max. lifting height of jib | m | 46.58 |
| Working speeds | Max. hoist rope speed(Main winch) | m/min | 135 |
| Max. hoist rope speed(Auxiliary winch) | m/min | 100 |
| Boom derricking up time | s | 40 |
| Boom derricking up time | s | 120 |
| Slewing speed | r/min | 2.6 |
| Driving | Max. driving speed | km/h | 72 |
| parameters | Max. gradeability | % | 34 |
| | Min. turning diameter | m | ≤20 |
| | Min. ground clearance | mm | 235 |
| | Limits for exhaust pollutants and smoke | | Comply with related standards |
| | Oil consumption per hundred kilometers | L | 38 |
| Mass | Deadweight in driving condition | kg | 29400 |
| Complete vehicle kerb mass | kg | 29270 |
| Front axle load | kg | 6370 |
| Rear axle load | kg | 22900 |
| Dimensions | Overall dimensions(L×W×H) | mm | 12510×2500×3455 |
| Outrigger spread(L) | m | 5.15 |
| Outrigger spread(W) | m | 6.1 |
| Main boom length | m | 10.3-38.5 |
| Boom angle | ° | -82 |
| jib length | m | 8 |
| Offset | ° | 0,30 |
| Chassis | Model | | ZLJ5323JQZ |
| Type | | II |
| Engine | Model | kw/r/min | WP6.240 |
| Rated power | n.m/r/min | 176/2300 |
| Max. output torque | | 900/1400 - 1600 |
| Manufacturer | | Zoomlion Heavy Industry Science and Technology Co., Ltd. |
