China Mini Hydraulic Telescopic Mobile Pickup Truck Crane Manufacturer (SQ4S3)
Hubei Jiaheng Technology Co., Ltd.- Certification：ISO9001
- Condition：New
- Maximum Lifting Height：10-15m
- Maximum Lifting Weight：2-4t
- Shaft Number：2
- Crane Jib：Three-Arm
Base Info
- Model NO.：SQ4S3
- Type：Straight Arm
- Material：HG70
- Max Lifting moment：100Kn.m
- Max Lifting Capacity：4T
- Max Lifting Height：10m
- Working Radius：8m
- Boom Section：3 stages
- Rotation Angle：360 degree All Rotaion
- Working Pressure：16MPa
- Rated Oil Flow：30 L,min
- Oil tank Capacity：100L
- Installation Space：800mm
- Swing type：Planetary gear reduction.
- Outrigger：adjustable, Hydraulic operating.
- Outrigger Span：2100-4300mm
- Winch type：hydraulic crane
- Transport Package：Nude or Customized
- Specification：1700kg crane weight
- Trademark：HBQZ
- Origin：China
- HS Code：8426910000
- Production Capacity：35 Unit,Units Per Month
Description
10.00R20 tubeless tire, 7 pieces including one spare tire
Our advantages:
1.Truck crane,mobile crane ,also called crane truck ,truck with crane ,truck mounted crane ,truck with telescopic boom crane ,truck with folding arm crane ,truck with knucle crane ,truck with hydraulic crane ,mobile crane truck ,truck with crane arm ,small truck with crane.It includes knuckle boom crane and telescopic.The Telescopic crane,named telescopic truck mounted crane, the one of lorry crane ,is easy to operate and more economical facility. The raise and down of telescopic cranes are driven by wire rope, easy to accurately control. The barycentre of the telescopic arm crane are far to the mounting point, beneficial for average the loading, the arm are more longer, with wide operating range.
2.Truck Mounted Crane,named tractor mounted crane,lorry crane , is a type of machine can carry heavy weights and transport them. The truck with crane mounted can load and unload the freight itself and don't need to employ another crane. The loader crane can freely route in 360 degrees, raise and extend, make the loading simple and economic. Compare to the mobile crane, truck loader cranes are more convenient and effective.This truck mounted cranes are a great way to move equipment from the truck base to the ground and back from the ground. They are usually flexible to transport and move heavy loads to high altitudes, such as stones, containers, etc., and are usually mounted on industrial dump trucks.
3.The material of telescopic boom truck mounted crane is used HG70 international standard high-strength steel to reduce the weight of crane.
4.The boom of telescopic boom crane is used hexagonal structure,reducing the lateral.
5. The balance valve,hydraulic lock,operated valve,hydraulic pump and other core parts of truck mounted crane to ensure the micro-mobility,security and stability is Italian brand
6.Our oil seal and gasket for hydraulic pump of truck mounted crane is Parker brand
7.The remote control operate of telescopic boom truck mounted crane is Sweden Brand scanreco.
8.We can provide truck mounted cranes for various brands of chassis, such as Dongfeng, Shanxi Automobile, Sinotruk, Dayun, Jiefang and so on.And my factory export department directly sale ,export experience more than 20 years with the drive type could be 4x2 , 4x4 , 6x2 , 6x4 , 6x6 , 8x4, providing LHD (left hand drive) and RHD (right hand drive) vehicles
Part 2-----OUR COMPANY
HUBEI BEST CRANE CO.,Ltd is located in the central of Hubei Province in China.We are a professional truck mounted crane manufacture, mainly engaged in researching, developing and manufacturing truck mounted cranes from 1 ton to 200 tons.
The Company has passed the ISO 9001-2008, and achieved the license of Special Equipment Manufacture Unit.
HUBEI CRANE is a wholly-owned subsidiary of HUBEI JIAHENG TECHNOLOGY CO.,LTD,which is formerly known as China famous hydraulic cylinder manufacture. The Head office JIAHENG was founed in 2001,the main products include a variety of special hydraulic cylinder.
After 20 years development,JIAHENG now covers an area of 200,000 Square meters, ownes a registered capital of 1000 million RMB,and 250 million RMB worth of fixed assets .JIAHENG has established long time cooperation with over 80 big companies like Zoomlion, Fukuda Fortaleza, CIMC Vehicle Group, and so on.
Our company have more than 800 units equipment for mass production.
We can product around 220 thround units per year of hydraulic cylinder and 500 units per year of truck crane.
Our company have more than 150 technical staff, Have more than 10 invention patents and 60 utility patents.
So we can produce customized products or develop new products.
