Popular 55ton Crawler Crane Zcc550h Zcc850h with Multiply Functions
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：Provided
- Max. Lifting Height：58m
- Rated Loading Capacity：55ton
- Certification：CE
- Condition：New
- Warranty：1 Year
Base Info
- Model NO.：ZCC550H
- Max. Lifting Moment：209t. M
- Max. Gradeability：30%
- L*W*H：13000*4600*3180mm
- Engine Rated Power：140kw
- Max. Torque：860n.M
- Transport Package：Provided
- Specification：49.2 ton
- Trademark：SINOMADA
- Origin：China
- HS Code：8429521200
- Production Capacity：100units,Month
Description
Overview
Hot Products
Item
Unit
Value
Main boom length
m
13~52
Fixed jib length
m
7~15
Main boom working angle
°
30~80
Fixed jib installation angle
°
10, 30
Hoisting mechanism Luffing mechanism Swing speed
rpm
0~2.45
Walking speed
km/h
0~1.65
Gradeability
%
30
Ground pressure
MPa
0.065
The weight of the whole machine
t
49.2
Counterweight
t
17.5
Overall dimensions length×width×height
mm
13000×4600(3120)×3180
engine
model
WP6G190E301
Rated power/speed
kW/rpm
140/2000
Track gauge × ground length × track shoe width
mm
2360×5000×760
mm
3840×5000×760
noise
Environmental radiation noise at work
dB
≤107
Manipulate indoor noise at work
dB
≤85
