180t Qay180 Truck Crane All Terrain Crane

Evangel Industrial (Shanghai) Co., Ltd.
  • After-sales Service：1 Year
  • Warranty：1 Year
  • Certification：CE, ISO9001
  • Condition：New
  • Maximum Lifting Height：>40m
  • Maximum Lifting Weight：>16t

Base Info

  • Model NO.：Qay180
  • Shaft Number：3
  • Crane Jib：Five-Arm
  • Type：Straight Arm
  • Max. Rated Lifting Capacity：60t
  • Engine Model：Cummins
  • Rated Power/Revolution Speed：250,2100 Kw, Rpm
  • Length-Full-Extend Boom+Jib：59.5 M
  • Swing Speed：0~2 R,Min
  • HVAC in up Cab：Cold
  • HVAC in Low Cab：Cooling and Heating
  • Overall Weight：42000kg
  • Front Axle Load：16000kg
  • Rear Axle Load：26000kg
  • Transport Package：Regular Package
  • Specification：13700*3750*3750
  • Origin：China
  • Production Capacity：100

Description

DimensionUnitQAY180Overall lengthmm15770Overall widthmm Overall heightmm4000Weight  Overall weight in transportkg60000Front axle loadkg Rear axle loadkg Power  Engine model TAD720VE    OM460LA.E3A/1Engine rated powerkW/(r/min)162/2100   360/1800Engine rated torqueN.m/(r/min)2200/1100Travel  Max. travel speedkm/h80Min. turning diameterm20Min. ground clearancemm Approach angle°16Departure angle°13Max. grade ability%50Fuel consumption for 100kmL Main performance  Max. rated total lifting capacityt180Min. rated working radiusmm Turning radius at turntable tailm Max. lifting torquekN.m5420Base boomm Fully extended boomm62Fully extended boom+ jibm Longitudinal outrigger spanm8.3Lateral outrigger spanm8.9Working speed  Boom luffing times Boom full extension times Max. swing speedr/min Max. speed of main winch (single rope) (no load)m/min Max. speed of aux. winch (single rope) (no load)m/min
