Strong Gradeability 100tons Rough Terrain Crane Rt100

Newindu Construction Engineering (Shanghai) Co., Ltd.

After-sales Service：Online Service
Warranty：One Warranty
Certification：ISO9001
Condition：New
Maximum Lifting Height：30-40m
Maximum Lifting Weight：>16t

Base Info

Model NO.：RT100
Shaft Number：3
Crane Jib：Five-Arm
Type：Straight Arm
Lateral Outrigger Span：6.9m
Max. Travel Speed：72km,H
Weight (Kg)：100000 Kg
Transport Package：Container Bulk Nude Frame
Specification：100000kg
Trademark：china top
Origin：China
HS Code：8705109200
Production Capacity：100pieces,Month

Description

ItemSpecificationUnitOverall Length12150mmOverall Width2625mmOverall Height3410mmWheel Base3720mmTotal vehicle mass intravel configuration32300kgAxle Load 16640+15660kg Engine Model --- Engine rated power119/2500kw/rpmEngine rated torque732/1500N.m/rpmMax. travel speed37km/hMin. turning diameter12.2/6.2mMax. gradeability75%Min. ground clearance400mmApproach angle23.9°Departure angle23.3°
Contact way

Sales Manager
Winnie Wan

Newindu Construction Engineering (Shanghai) Co.,Ltd
Add: Suite 2801, Super Ocean Finance Center,2067 West Yan'an Road, Shanghai 200336, China

Company Profile
