Single Girder 10 Ton Bridge Cranes (LDA, LX, LDP, SDQ)

Henan Kuangshan Crane Co., Ltd.
  • Certification：ISO9001: 2000, Ce
  • Condition：New
  • Operation Form：Ground Operation
  • Maximum Lifting Height：25-30m
  • Maximum Lifting Weight：<20t
  • Main Girder Form：Single Girder

Base Info

  • Model NO.：LDA, LX, LDP, SDQ
  • Type：Single Girder Crane
  • Travelling Speed：20, 30m,Min
  • Power：2*0.8kw, 2*1.5kw
  • Electric Hoist Equipped：CD1,MD1 (Single- or Dual- Lifting Speed)
  • Lifting Speed：8, 7, 4, 3.5m,Min
  • Lift Height：3m, 6m, 9m, 12m, 18m, 24m, 30m
  • Cross Traveling：20m,Min
  • Working Duty：A3,M3
  • Motor：Cone Squirrel-Cage Model
  • Power Supply：220V~480V 50,60Hz
  • Wheel Dia.：270mm
  • Application：Workshop Usage, Construction Usage
  • Sling Type：Wire Rope
  • Power Source：Electric
  • Transport Package：Exporting Standard
  • Specification：JB,T1306-2008
  • Trademark：Kuangyuan
  • Origin：China
  • HS Code：8426112000
  • Production Capacity：26000sets,Year for This Type Crane

Description

Lifting CapacityT 1t2t3t5t10t 16t20t Spanm 7.5~22.5m7.5~31.5 SpeedLiftingMD1 hoistm/min8/0.8 (7/0.7) 3.5/0.35CD1 hoist8 (7)  3.5Traveling of electric hoist 20  20Traveling of crane20/30 20/30Wheel diameterΦ270Φ370Width of trail37~70mm37~70mmOperational Modelremote control; ground handleremote control; ground handleWorking DutyA3A3Power SupplyThree-phase A.C. 380V, 50HzThree-phase A.C. 380V, 50HzSingle Girder 10 Ton Bridge Cranes (LDA, LX, LDP, SDQ)Single Girder 10 Ton Bridge Cranes (LDA, LX, LDP, SDQ)Single Girder 10 Ton Bridge Cranes (LDA, LX, LDP, SDQ)Single Girder 10 Ton Bridge Cranes (LDA, LX, LDP, SDQ)Single Girder 10 Ton Bridge Cranes (LDA, LX, LDP, SDQ)Single Girder 10 Ton Bridge Cranes (LDA, LX, LDP, SDQ)Single Girder 10 Ton Bridge Cranes (LDA, LX, LDP, SDQ)
