Sinomada Certificated Construction Machinery Lifting Equipment Telescopic Mobile Crane
Sinomada Heavy Industry (Changsha) Co., Ltd.- After-sales Service：Any
- Warranty：1 Year Warranty
- Certification：CE, ISO9001
- Condition：New
- Maximum Lifting Height：25.8m
- Maximum Lifting Weight：10t
Base Info
- Model NO.：SPC120T
- Shaft Number：2
- Crane Jib：Three-Arm
- Type：Folding
- Transport Package：Roro
- Specification：14100*2800*3600 mm
- Trademark：LIUGONG
- Origin：China
- HS Code：8426120000
- Production Capacity：500,Month
Description
Speed parameter
Maximum single rope speed of main winch
120m/min
Boom fully extended/retracted time
38/35s
Full lifting/falling time of boom
38/35s
Maximum turning speed
2.5r/min
Weight parameter
Total weight of the whole machine
17130kg
Maximum counterweight
2.846t
Size parameters
Overall length
11240mm
Overall width
2500mm
Overall height
3450mm
Outrigger span (horizontal x longitudinal)
5.8x4.9m
Dynamic parameters
engine model
Dongkang ISD210 50 (National V)
Maximum engine power
155/2500kW/rpm
Engine maximum output torque
800/(1100-1700)N·m/rpm
Driving parameters
Maximum travel speed
90km/h
Minimum turning radius
9m
Maximum grade
40%
Approach angle
21°
Departure angle
11°
Minimum ground clearance
250mm
