Crane

Saj-30~70 Construction Hoist Anti-Fall Safety Device

Shanghai Strong Engineering Construction Co., Ltd.
  • Certification:CE
  • Condition:New
  • Maximum Lifting Weight:150-200t
  • Maximum Lifting Height:>40m
  • Operation Form:Crane Console
  • Type:Hydropower Station Gantry Crane

Base Info

  • Model NO.:SAJ 30,40,50,60,70
  • Main Girder Form:Single Girder
  • Rated Braking Speed:2.0 M,S
  • Hoisting Speed:1.2m,S
  • Weight(Kg):38.5
  • Loder Weight:for Sc100 and Sc200
  • Model Number:Saj50
  • Color:Depend on Your Requirement
  • Applicable Models:Low-Speed Construction Hoist
  • Transport Package:Wooden Case
  • Specification:SAJ 30,40,50,60,70
  • Trademark:SRIBS
  • Origin:Shanghai
  • HS Code:84313900
  • Production Capacity:20000PCS,Year

Description


Characteristics
Model
Rated Loading
Lifting Speed
Motor Power


Double Cabin


Low-speed
SC200/200D
 2×2000kg
0-33m/min
2×(3×11kw)
SC100/100D
 2×1000kg
0-33m/min
2×(2×11kw)

Mid-speed
SC200/200Z
 2×2000kg
0-55m/min
2×(2×11kw)
SC100/100Z
 2×1000kg
0-55m/min
2×(2×11kw)

Single
Cabin

Low-speed
SC200D
    2000kg
0-33m/min
3×11kw
SC100D
    1000kg
0-33m/min
2×11kw

Mid-speed
SC200Z
    2000kg
0-55m/min
2×11kw
SC100Z
    1000kg
0-55m/min
2×11kw

 The anti-drop safety devcie is consistent with China National Standards; also reach Hong Kong COP Standards and Europe EN Standards.
SAJ40-1.2 is one of safety devices for SC200/200. Other safety device including:
Top and bottom limit, cage door electrical and mechanical interlock safety device, landing door electrica and mechanical interlock, anti-exceeding top device, safety hook, anti-overload device, etc.
SC200/200 construction lifting hoist:
1.Cage capacity: 2000kg
2.Lifting speed: 33m/min
3.Mast section: painted or hot galvanized
4.Height: customized
5.Cage size:3.0x1.5x2.2

Anti-drop safety device are including:
SAJ30-1.2, SAJ30-1.4;
SAJ40-1.2, SAJ40-1.4;
SAJ50-1.2, SAJ50-1.4
ETC.

Technical parameters

Model
Rated LoadRated SpeedCalibration speedSAJ08-1.00.8T1.0m/sUpon requestSAJ30-1.23.0T1.2m/sUpon requestSAJ30-1.43.0T1.2m/sUpon requestSAJ40-1.2A4.0T1.2m/sUpon requestSAJ40-1.44.0T1.4m/sUpon requestSAJ40-2.04.0T2.0m/sUpon requestSAJ50-1.25.0T1.2m/sUpon requestSAJ50-2.05.0T2.0m/sUpon requestSAJ60-1.26.0T1.2m/sUpon requestSAJ60-2.06.0T2.0m/sUpon request
