• Model NO.：QD
• Maximum Lifting Weight：10~100ton
• Main Girder Form：Double Girder
• Type：Ordinary
• Product Name：Pakistan Workshop 10 20 30 50 Ton Power Plant Over
• Power Supply：3pH AC
• Main Hook Lifting Speed：5.9m,Min
• Auxiliary Hook Lifting Speed：10.4m,Min
• Sling Type：Wire Rop
• Max. Lifting Height：30m
• Lifting Machine：Trolley
• Working Class：A5-A7
• Span：10.5-31.5m
• Color：Yellow or Customized
• Lifting Height：6m,9m,12m,18m,24m,30m or Customized
• Packing：Export Standard
• Transport Package：Standard Export Package
• Specification：50,10 ton
• Trademark：NYBON
• Origin：Henan
• HS Code：84261120
• Production Capacity：300set,Year

Lifting Capacity

T

5

10

16/3.2

20/5

32/5

50/10

Span

m

10.5-31.5

Speed

Main Hook Lifting

A5

m/min

11.3

8.5

7.9

7.2

7.5

5.9

A6

15.6

13.3

13

12.3

9.5

7.8

Aux. Hook Lifting

16.7

19.5

19.5

10.4

Traveling of Trolley

37.2

43.8

44.6

44.6

42.4

38.5

Traveling of Crab

A5

89.8/91.8

90.7/91.9/84.7

84.7/87.6

84.7/87.6

87/74.2

74.6

A6

92.7/93.7

115.6/116/112.5

112.5/101.4

112.5/101.4

101.4/101.8

75/76.6

Operational Model

Cabin; remote control

Working Duty

 A5,A6

Power Supply

Three-phase A.C. 380V, 50Hz or customized

Overhead Crane Option:

Pendent line control, Cabin control and remote control

SCHNEIDER, SIEMENS, CHINT

SCHNEIDER, SIEMENS, CHINT, YASKAWA

XINDALI, JMU, ABM. ABB, WEG. SIEMENS or any special specified

TAILONG, TAIXING, SEW or any special specified

A5/A6/A7/A8

YES/NO

YES/NO

We can design and manufacture all kinds of non-standard product according to your requirement

1. Q: What's your MOQ?

  A: 1 Set;

2. Q: What's your package?

  A: Main body in plywood box or in plastic woven cloths; Spare parts in plywood boxes;

3. Q: What's your delivery period?

  A: Within 10/25/40 days after your prepayment received; exact period should be based on detailed requirements and actual period;

4. Q: What's your warranty period?

  A: 12 months from winches accepted;

5. Q: Do you have engineer oversea installation service?

   A: Yes; We have;

6. Q: What kinds of products do you have?

    A: All kinds of industrial electric winch (especially non-standard); Overhead Crane; Gantry Crane, Electric Hoist; Screw Hoist; Radial/Flat Gate Hoist; Steel Gate; etc.

7. Q: Could we buy spare parts in local once they are out of work?

    A: Our main electrical parts brand is Siemens or Schneider brand; it's very easy to buy all the world. But if there is any difficulty, we can post to you by express, such as DHL, UPS, FEDEX, Aramex, etc.

8. Q: Do you provide lift tools?

    A: Yes, we can provide any kinds of lift tools such as lift sling belt, lift clamp, grab, magnet , pulley blocks, hook, lock catch, wire rope, fiber rope, etc.

9. Q: Could your winches drag inclined?

    A: Yeah, our electric winches could drag horizontal, drag inclined, hoisting vertical.
