5 Ton Underslung Suspension Overhead Crane

HENAN NYBON MACHINERY CO., LTD.
  • Certification：CE
  • Condition：New
  • Operation Form：Ground Operation
  • Maximum Lifting Height：25-30m
  • Maximum Lifting Weight：<20t
  • Main Girder Form：Single Girder

Base Info

  • Model NO.：LX
  • Type：Ordinary
  • Product Name：10 Ton Single Girder Overhead Bridge Crane
  • Power Supply：3pH AC
  • Lifting Speed：7-8m,Min
  • Cross Travelling Speed：20m,Min
  • Crane Travelling Speed：20m,Min
  • Working Class：A3
  • Lifting Mechanism：Wire Rope Hoist
  • Similar Model：Ldp,Ldc,Lb,Lz
  • Recommended Rail Width：37~70mm
  • Lifting Height：6,9,12,18,24,30m
  • Transport Package：Standard Export Package
  • Specification：10 ton
  • Trademark：NYBON
  • Origin：Henan
  • HS Code：84261120
  • Production Capacity：120set,Month

Description

Capacity

t

1,2,3,5,10

16,20

Span

m

                               7.5-22.5

Lifting height

m

6,9,12,18,24,30

12,18,24,30



Speed

Lifting

m/min

8,8/0.8,7/07

3.5,3.5/0.35

Cross travel

m/min

20,30

20,30

Long travel

m/min

                               20,30,45,60,75

Electric hoist

type

CD/MD

CD/MD/HC

Working duty



A3

A3

Power supply

AC

380V/50HZ/3P

380V/50HZ/3P


5 Ton Underslung Suspension Overhead Crane

5 Ton Underslung Suspension Overhead Crane
5 Ton Underslung Suspension Overhead Crane5 Ton Underslung Suspension Overhead Crane

1. Q: What's your MOQ?

  A: 1 Set;

2. Q: What's your package?

  A: Main body in plywood box or in plastic woven cloths; Spare parts in plywood boxes;

3. Q: What's your delivery period?

  A: Within 10/25/40 days after your prepayment received; exact period should be based on detailed requirements and actual period;

4. Q: What's your warranty period?

  A: 12 months from winches accepted;

5. Q: Do you have engineer oversea installation service?

   A: Yes; We have;

6. Q: What kinds of products do you have?

    A: All kinds of industrial electric winch (especially non-standard); Overhead Crane; Gantry Crane, Electric Hoist; Screw Hoist; Radial/Flat Gate Hoist; Steel Gate; etc.

7. Q: Could we buy spare parts in local once they are out of work?

    A: Our main electrical parts brand is Siemens or Schneider brand; it's very easy to buy all the world. But if there is any difficulty, we can post to you by express, such as DHL, UPS, FEDEX, Aramex, etc.

8. Q: Do you provide lift tools?

    A: Yes, we can provide any kinds of lift tools such as lift sling belt, lift clamp, grab, magnet , pulley blocks, hook, lock catch, wire rope, fiber rope, etc.

9. Q: Could your winches drag inclined?

    A: Yea, our electric winches could drag horizontal, drag inclined, hoisting vertical.
