Used XCMG 70ton Truck with Crane Mobile
Henan Tarzan Industrial Co., Ltd.- After-sales Service：Available
- Warranty：Available
- Certification：GS, RoHS, CE, ISO9001
- Condition：Used
- Maximum Lifting Height：>40m
- Maximum Lifting Weight：>16t
Base Info
- Model NO.：QY70K-1
- Shaft Number：4
- Crane Jib：Five-Arm
- Type：Straight Arm
- Year：2013
- Transport Package：Seaworth Packing
- Origin：China
Description
Overview
Dimension Unit QY70K-I Overall length mm 13 930 Overall width mm 2 800 Overall height mm 3 575 Weight Total weight in travel kg 43 000(without 1t vice counterweight) Front axle load kg 17 000 Rear axle load kg 26 000 Power Engine model WD615.338(domestic III) Engine rated power kW/(r/min) 276/2200 Engine rated torque N.m/(r/min) 1500/1400 Travel Max. travel speed km/h 80 Min. turning diameter m 24 Min. ground clearance mm 327 Approach angle ° 19 Departure angle ° 13 Max. grade ability % 40 Fuel consumption for 100km L 45 Main performance Max. rated total lifting capacity t 70 Min. rated working radius m 3 000 Turning radius at turntable tail m 3.55 Max. lifting torque kN.m 2 303 Base boom m 11.6 Fully extended boom m 44.5 Fully extended boom+ jib m 59.5 Longitudinal outrigger span m 6.1 Lateral outrigger span m 7.3 Working speed Boom luffing time s 60 Boom full extension time s ≤150 Max. swing speed r/min ≥2.0 Max. speed of main winch (single rope) (no load) m/min ≥130 Max. speed of aux. winch (single rope) (no load) m/min ≥108
Product Description
Product Parameters
Company Profile
