70t 70 Tons Qy70K-I (hydraulic control) Truck Crane Top Brand

Evangel Industrial (Shanghai) Co., Ltd.

After-sales Service：1 Year
Warranty：1 Year
Certification：ISO9001
Condition：New
Maximum Lifting Height：>40m
Maximum Lifting Weight：>16t

Base Info

Model NO.：QY70K-I(hydraulic control)
Shaft Number：3
Crane Jib：Four-Arm
Type：Folding
Specification：13300*3490*3450
Origin：China
Production Capacity：100

Description

DimensionUnitQY70K-IOverall lengthmm13930Overall widthmm2800Overall heightmm3575Weight Total weight in travelkg43000(without 1t vice counterweight)Front axle loadkg17000Rear axle loadkg26000Power Engine model WD615.338(domestic III)Engine rated powerkW/(r/min) 276/2200Engine rated torqueN.m/(r/min)1500/1400 Travel Max. travel speedkm/h80Min. turning diameterm24Min. ground clearancemm327Approach angle°19Departure angle°13Max. grade ability%40Fuel consumption for 100kmL45Main performance Max. rated total lifting capacityt70Min. rated working radiusm3000Turning radius at turntable tailm3.55Max. lifting torquekN.m2303Base boomm11.6Fully extended boomm44.5Fully extended boom+ jibm59.5Longitudinal outrigger spanm6.1Lateral outrigger spanm7.3Working speed Boom luffing times60Boom full extension times ≤150Max. swing speedr/min ≥2.0Max. speed of main winch (single rope) (no load)m/min ≥130Max. speed of aux. winch (single rope) (no load)m/min≥108 Product Information
70t 70 Tons Qy70K-I (hydraulic control) Truck Crane Top Brand
