• Model NO.：XCT75
• Crane Jib：Five-Arm
• Type：Straight Arm
• Max. Rated Lifting Capacity：75t
• Max Load Moment：280kn.M
• Fixed Jib Length：9-18mm
• Max. Travel Speed：7.2km,H
• Transport Package：Nude Package
• Specification：ISO, CE
• Trademark：Evangel
• Origin：Jiangsu, China
• Production Capacity：50units,Month

Item
Unit
Parameter
Max. rated lifting capacity
Basic boom
t
75
Fixed jib
t
6.5
Max. lifting moment
kN.m
280
Boom length
m
13~58
Boom luffing angle
°
30~80
Fixed jib length
m
9~18
Max. single line speed for hoist mechanism (no load, at 5th layer )
m/min
120
Max. single line speed for boom luffing mechanism(at 1st layer)
m/min
57
Max. swing speed
r/min
2.4
Max. travel speed
km/h
7.2
Gradeability
%
30
Average ground pressure
MPa
0.087
Engine power
kW
200
Overall weight(main lifting hook,13m boom)
t
61
Max. single unit weight for transportation
t
39
Max. single unit dimensions for transportation(L×W×H)
m
12.6×3.32×3.23
