• Model NO.：QY35V
• Max. Lifting Height of Fly Jib：56m
• Outline Dimensions：12620*2500*3400 mm
• Tower Crane Type：Slewing Tower Crane
• Sling Type：Wire Rope
• Main Girder Form：Single Girder
• Power Source：Hydraulic
• Moving Type：Wheel
• Installation：Assembled
• Transport Package：Nude Packing
• Specification：CE, ISO9001
• Trademark：ZOOMLION
• Origin：Jiangsu, China
• HS Code：87051092
• Production Capacity：100 Set,Sets , Month

Type
Ser. No.
Item
Unit
Value
Working performance
1
Max. rated lifting weight × working radius
kg.m
35000×3.0
2
Max. lifting torque of basic boom
kN.m
1430
3
Max.lifting torque of longest main boom
kN.m
768
4
Max. lifting height of longest main boom
m
41.7
5
Max. lifting height of jib
m
56.4
Dimensions
6
Outline dimensions (L×W×H)
mm
13200*2650*3625
7
Distance between outriggers (longitudinal × transversal)
mm
5360×6100
8
Main boom length (completely retracted - completely extended)
m
12.0
9
Jib length
m
9
10
Main boom angle of elevation
°
-2~80
11
Swing range

360°continuously
Working speed
12
Max.speed of single rope on the drum of main winch
m/min
120
13
Boom extension time
s
110
14
Boom derricking up time
s
45
15
Swing speed
r/min
0~2
Mass
16
Complete vehicle kerb mass
kg
34470
17
Front axle load
kg
8600
18
Rear axle load
kg
26000
Traveling
19
Max. traveling speed
km/h
75
20
Max. gradeability
%
34
21
Min. turn radius
m
24
22
Min. ground clearance
mm
272
