HBQZ China Manufacturers 3.2 Ton Hydraulic Truck Mounted Mobile Telescopic Boom Crane Truck with Grab (SQ3.2S3)

Hubei Jiaheng Technology Co., Ltd.
  • Certification：ISO9001
  • Condition：New
  • Maximum Lifting Height：10-15m
  • Maximum Lifting Weight：2-4t
  • Shaft Number：2
  • Crane Jib：Three-Arm

Base Info

  • Model NO.：SQ3.2S3
  • Type：Straight Arm
  • Material：HG70
  • Max Lifting moment：80Kn.m
  • Max Lifting Capacity：3.2T
  • Max Lifting Height：10m
  • Working Radius：7.4m
  • Boom Section：3 stages
  • Keywords：telescopic truck crane
  • Working Pressure：16MPa
  • Rated Oil Flow：30 L,min
  • Oil tank Capacity：100L
  • Crane type：telescopic truck crane
  • Swing type：Planetary gear reduction
  • Hot points：telescopic truck crane
  • Outrigger Span：1750-3550mm
  • Installation Space：800mm
  • Transport Package：Nude or Customized
  • Specification：1500kg Truck mounted crane manufacturers
  • Trademark：HBQZ
  • Origin：China
  • HS Code：8426910000
  • Production Capacity：35 Unit,Units Per Month

Description

Max Lifting Capacity (kg/m)3200/2.51100/4800/5.3400/7.4Max Lifting Height10mWorking Radius7.4mBoom Section3 stagesRotation Angle360°All RotaionWorking Pressure16mpaRated Oil Flow30 L/minOiltank Capacity100LWinchtypeHydraulicSwingtypePlanetary gear reduction.Outriggeradjustable, Hydraulic operating.Outrigger Span1750-3550mmCrane Weight1500 kgInstallation Space800mmSafety DeviceLoad Indicator, Hydraulic Safety Valve, Counter Balance Valve, Automatic Swing Brake, Hook Safety Device.MaterialHG70 10.00R20 tubeless tire, 7 pieces including one spare tire
HBQZ China Manufacturers 3.2 Ton Hydraulic Truck Mounted Mobile Telescopic Boom Crane Truck with Grab (SQ3.2S3)
HBQZ China Manufacturers 3.2 Ton Hydraulic Truck Mounted Mobile Telescopic Boom Crane Truck with Grab (SQ3.2S3)
HBQZ China Manufacturers 3.2 Ton Hydraulic Truck Mounted Mobile Telescopic Boom Crane Truck with Grab (SQ3.2S3)
HBQZ China Manufacturers 3.2 Ton Hydraulic Truck Mounted Mobile Telescopic Boom Crane Truck with Grab (SQ3.2S3)HBQZ China Manufacturers 3.2 Ton Hydraulic Truck Mounted Mobile Telescopic Boom Crane Truck with Grab (SQ3.2S3)
