Small 6.3 Ton Telescopic Truck Boom Mounted Crane Specification

XUZHOU BOB-LIFT CONSTRUCTION MACHINERY CO., LTD.
  • After-sales Service：Yes
  • Warranty：1year
  • Certification：ISO9001
  • Condition：New
  • Maximum Lifting Height：13m
  • Maximum Lifting Weight：6.3ton

Base Info

  • Model NO.：SQ6.3SA3
  • Shaft Number：2
  • Crane Jib：Three-Arm
  • Type：Straight Arm
  • Product Name：Winch Crane
  • Color：Optional
  • Usage：for Truck
  • Brand：Bob-Lift
  • Model：Sq6.3SA3
  • Working Radius：11.26 M
  • Max Elevation Angle：75 Degree
  • Feature：Truck Mounted Crane
  • Crane System：Hydraulic System
  • OEM：Accept
  • Transport Package：Wooden Box
  • Specification：4550*820*500 mm
  • Trademark：BOB-LIFT
  • Origin：Xuzhou City Jiangsu Province
  • HS Code：84269100
  • Production Capacity：120 Per Month

Description

Straight Arm Hydraulic Winch Crane Truck for SaleMax Lifting CapacityTon5Max Lifting MomentTon.m12.5Recommend PowerKW18Hydraulic System FlowL/min32Hydraulic System PressureMPa20Oil Tank CapacitL100Installation Spacemm850Self Weightkg2050Rotation Angle°360
Small 6.3 Ton Telescopic Truck Boom Mounted Crane SpecificationSmall 6.3 Ton Telescopic Truck Boom Mounted Crane Specification

3) Packing and Shipping
 20GP container: 4 units40HQ container: 8 unitsStandard packing for export, container shipping.Small 6.3 Ton Telescopic Truck Boom Mounted Crane Specification

4) Our service
 1. Brand new truck mounted crane .2. Solve all problem at the first time.3. Made-in-China verified supplier.4. Fast & Thoughtful service.5. Engineer can be supplied for oversea service after negociation.6. 12-Months Guarantee.
