• Model NO.：QTZ63
• Type：Tower Crane
• Max.Load：8tons
• Tip Load：1.5t at 60m, 2t at 55m, 2.5t at 50m, 3.0t at 45m
• Jib Length：60m
• Basic Height：60m
• Max Height：200m
• Mast Section：2000*2000*3000mm
• Section Type：Angle Steel
• Power Source：Electric
• Sling Type：Wire Rope
• Brand：Oriemac
• Transport Package：Standard Seaworthy Package Via 40hq
• Specification：CE, ISO, SGS, GOST, TUV
• Trademark：ORIEMAC
• Origin：Jiangsu, China.
• HS Code：84292090
• Production Capacity：200 Units,Month

Basic Info.

Model NO. QTZ63 Type Tower Crane Max.Load 8tons Tip Load 1.5t at 60m, 2t at 55m, 2.5t at 50m, 3.0t at 45m Jib Length 60m Basic Height 60m Max Height 200m Mast Section 2000*2000*3000mm Section Type Angle Steel Power Source Electric Sling Type Wire Rope Brand Oriemac Transport Package Standard Seaworthy Package Via 40hq Specification CE, ISO, SGS, GOST, TUV Trademark ORIEMAC Origin Jiangsu, China. HS Code 84292090 Production Capacity 200 Units/Month

Product Description

Specification of  Tower Crane

•  TOP 5 IN CHINA
• HAVE 40 YEARS EXPERIENCE IN THIS AREA
• 4, 600 STAFFS

1) Steel structure

Steel is the essential safety guarantee for tower crane. The steel we use for our tower crane is tower crane usage special square steel from Wuhan Iron and Steel Group. Steel material for those essential parts like lifting jib, tower top, frame etc is 16 Manganese Steel. Thus to assure safety, advance and high performance of the crane.

2) Hoisting Mechanism

We apply following technology of mature three velocity-variation pole motor, big center distance speed reducer, big diameter drum to effectively enhance the life span of crane. And the equipped rope mechanism solves the rope disorder issue effectively. The crane is specially equipped with hydraulic push brake to assure stable and reliable braking and easy maintenance.

3) Swing Mechanism

The speed change system is by rheostat variation of wound rotor motor or by frequency change system. The swing of tower crane is flexible, stable, exact positioning, highly reduced swing impact force and with high safety performance.

4) Luffe

It applies double-speed or three-speed motors for speed change control according to the jib length, easy running control, low impact force,high operation stability and high efficiency.

5) Control System

The Electric elements are from Schneider Company to assure high system reliability. The control cables uses air plug for easy and fast assembling and maintenance.

6) Operating System

Newly spacecraft type cabinet room with air conditioning system, wide eye view, high consideration of operator comfortableness and maximally to low down operation fault rate.

7) Security Guards

Except for using the common security devices, we uniquely equips high definition operation tracking monitor system which can thoroughly supervise the lifting hook, ground and construction building and can assure safety operation when with sight blockage.

Type	QTZ80
Basic heigh60	60m
Max height	200m
Length	60m/55m/50m/45m
Max load	10t
Tip load	1.5t/2.0t/2.5t/3.0t
Section size	2000*2000*3000mm
Section	Angle steel
