Official Zoomlion Xuzhou San Y 5-Section 50 Ton Truck Crane Qy50kd Ztc500h Stc500e
Maxizm Construction Machinery (Qingdao) Co., Ltd.- After-sales Service：Online Support
- Warranty：One Year Warranty
- Certification：CE, ISO9001
- Condition：New
- Maximum Lifting Height：>40m
- Maximum Lifting Weight：>16t
Base Info
- Model NO.：QY50KD
- Shaft Number：2
- Crane Jib：Five-Arm
- Type：Straight Arm
- Emission：Eurov
- Engine Brand：HOWO
- Rated Power：276 Kw
- Max. Lifing Height：57.7 M
- Max. Lifing Moment of Basic Boom：1764 Kn.M
- Transport Package：Nude Packing
- Specification：13930*2500*3400mm
- Trademark：MAXIZM
- Origin：Xuzhou, China
- HS Code：8705109200
- Production Capacity：100units,Month
Description
Parameter valueOverall length mm 13930 Overall width mm 2780 Overall Height mm 3630 Axle base 1st ,2nd axle mm 1470 2nd ,3rd axle 4300 3rd ,4th axle 1350 Wheel Base mm 2304+2075 Front overhang/rear overhang mm 2389/2064or 2376/2064 Front extension/rear extension mm 2131/226 or 2144/226 Total vehicle mass in travel configuration kg 42200 Axle load Front axle kg 16200 Rear axle 26000 Engine Model WD615.338 Engine rated power kw/(r/min) 276/2200 Engine rated torque N.m/(r/min) 1500/1300-1600 Max. travel speed km/h 85 Min. steady travel speed km/h 2~3 Min. turning diameter m 24 Min. ground clearance mm 327 Max. grade ability % 42 Approach angle ° 19 Departure angle ° 15 Braking distance (at 30 km/h, full load ) m ≤10 Oil consumption per 100km L 40 Exterior noise level during acceleration traveling dB (A) ≤88 Noise level at seated position dB (A) ≤90
