• Model NO.：ZCC100H
• Fixed Jib Length：6 - 15m
• Max. Lifting Capacity × Radius：55*3.7
• Traveling Speed：0-1.6km,H
• Max. Gradeability：30
• Slewing Speed：0-2.1rpm
• Transport Package：Nude Packing
• Specification：(13.8*3.4*. 35)
• Trademark：Zoomlion
• Origin：China
• HS Code：84262000
• Production Capacity：1000 Unit Per Year

Max. lifting capacity / radiusUS Tons/ft(mt/m)110/10'6"(100/3.2)Max. lifting capacity of fixed jibUS Tons (mt)8.8(8)Main boom lengthft(m)42'8"-219'10"(13-67)Fixed jib lengthft(m)180'5"+59'(55+18)Main boom angle.30-82.5Fixed jib angle.10,30Rope speed of hoisting winches 1 and 2With free-fall functionft/min(m/min)325(99)Without free-fall functionft/min(m/min)393(120)Single rope speed of derricking winchft/min(m/min)190(58)Max./rated single rope force of hoisting winches 1 and 2With free-fall functionLbs(mt)44100/29988(20/13.6)Without free-fall functionLbs(mt)31311/27342(14.2/12.4)Slewing speedr/min

0-2.3

Traveling speed(high/low speed)mph(km/h)0.78/0.31(1.25/0.5)Gradeability%(°)30%(16.7°Max.transport weight of basic machineLbs(mt)99887(45.3)Deadweight(with basic boom)Lbs(mt)189630(86)CounterweightLbs(mt)61740(28)22050(10)Slewing radiusft(m)15'5"(4.7)Overall dimensions(L × W × H)m45'3"×11'2"×11'(13.8×3.4×3.35)Ground clearance of the undercarriageft(mm)17"(437)EngineType QSL9-280Rated powerHP@RPM(Kw@RPM)280@2100(209@2100)Max. output torqueLbs?ft@RPM(N?m@RPM)1050@1500(1424@1500)Exhaust standard According to U.S.EPA Tier 3
