Ztc500h552 Truck Crane 50 Ton Construction Hoisting Machinery
Evangel Industrial (Shanghai) Co., Ltd.- Certification：CE, ISO9001
- Condition：New
- Maximum Lifting Height：>40m
- Maximum Lifting Weight：>16t
- Shaft Number：4
- Crane Jib：Five-Arm
Base Info
- Model NO.：ZTC500H552
- Type：Straight Arm
- Transport Package：Bulk Roro Container
- Specification：14100*2650*3800
- Trademark：Zoomlion
- Origin：China
- Production Capacity：1000,Year
Description
ItemSpecificationRemarkPerformanceMax. loading capacity50000kg Max. lifting moment-Base boom 1813 kN.m Max. lifting moment-Full-extend boom 1082 kN.m Max. lifting height of Length-Base boom12.6m Max. lifting height Length-Full-extend boom45.5m Max. lifting height Length-Full-extend boom+jib61mSpeedMax. single rope lifting speed of main winch135 m/min Max. single rope lifting speed of auxiliary winch.125 m/min Full extend/retract time of boom50s Full raise/lower time of boom110s Swing speed0~2.2 r/min DrivingMax. elevation2000m Max. driving speed80 km/h Max. gradeability44% Min. turning radius≤24m Min. ground clearance280mm Fuel consumption per 100km41L WeightOverall weight41600kg Curb weight 41405kg Front axle load 15600kg Rear axle load 26000kg DimensionOverall dimension14100×2650×3800 Outrigger span (Longitudinal) 7.4m Outrigger span ( Transversal)6.05m Tail swing radius of superstructure3890mm Length of Full-extend boom 11.6~45 Approach angle -2~80 ° Length of Jib 9.5 ,16.0m Angle of jib 0 ,15,30 °
