• Model NO.：RT25
• Type：Straight Arm
• Max.Total Lifting Capacity：25t
• Boom Demrricking up Time：40s
• Min.Ground Clearance：568mm
• Full-Extended Boom：38.2m
• Front Axle：17750kg
• Overalmax.Gradeabilityl Width：55%
• Longest Main Boom：31 M
• Min Travel Speed：2 Km,H
• Transport Package：Nude
• Specification：11952*2980*3450mm
• Trademark：China
• Origin：Jiangsu, China
• HS Code：8501101000
• Production Capacity：100units,Week

CategoryItemParameterAllowance
DimensionOverall lengthmm11952±1%Overall widthmm2980-1%~0Overall heightmm3450-1%~0Wheel basemm3700±1%Track (front/rear)mm2440±1%Front/rear overhangmm1900/2151±1%Front/rear extensionmm4201/0±1%
WeightKerb masskg30300±3%Axle load1st Axlekg15100±3%2nd Axlekg15200±3%




TravelMax. travel speedkm/h25≥Min. turning radiusm5.7    (4 wheels), 9.6 (2 wheels)±3%Min. ground clearancemm400±1%Approach angle°23±1°Departure angle°20±1°Braking distance (at 24 km/h)m9≤Max. grade-ability%55≥


PowerEngine model QSB6.7-C190/Rated engine powerkW142 /Engine rated rotation speedr/min2200/Engine emission standard off-road   EU Stage IIIA/Driving type 4×2, 4×4/Tire specifications 20.5R25/Number of tires 4/
[Product Picture]
