Item | Unit | Value | Remarks |
---|
Max. lifting capacity × radius | t × m | 55×3.7 | |
Max. lifting capacity on fixed jib | t | 5.5 | |
Max. lifting capacity of luffing jib | t | 12 | |
Main boom length | m | 13 - 52 | |
Fixed jib length | m | 6 - 15 | |
Max. length of main boom with fixed jib | t | 43+15 | |
Luffing jib length | m | 16m-28m | |
Max. main boom +max. luffing jib | m | 40mm+28mm | |
Derricking angle | . | 30 - 80 | |
Fixed jib angle | . | 10,30 | |
Max. rope speed of winches | Hoisting winch 1 | m/min | 125/100 | With optional free-fall function |
Hoisting winch 2 | 125 | |
Derricking winch | 80 | |
Slewing speed | rpm | 0-2.1 | |
Traveling speed | km/h | 0-1.6 | |
Max. gradeability | % | 30 | With basic boom and counterweight over front |
Ground pressure | Mpa | 0.068 | |
Deadweight | t | 50.5 | With basic boom |
Crane counterweight | t | 17.5 | |
Overall dimensions(L × W × H) | m | 12800×4600(3300)×3120 | With A-frame and main boom pivot section |
Engine | Model | | WP6G190E26 | Manufacturer:Weichai Power CO, Ltd. |
Rated power / rotational speed | kW/r/min | 140/1900 |
Max. output torque /rotational speed | Nm/r/min | 830/1300 |
Exhaust emission | | National Stage |
Distance between track center × crawler contact length × crawler width | mm | 2540 ×5000×760 | Crawler carrier retracted |
3840 ×5000×760 | Crawler carrier extended |
Noise | Noise level outside operator's cab during operation | (dB) | ≤107 | |
Noise level in operator's cab during operation | ≤85 | |
