China Top Brand Zoomlion 55ton Crawler Crane Zcc550h-1 for Sale

Sinomada Heavy Industry (Changsha) Co., Ltd.

Max. Lifting Height：52m
Rated Loading Capacity：55ton
Certification：ISO9001, CE
Condition：New
Max. Load Moment of Basic Boom：55*3.7 T.M
Main Boom Length：13-52m

Base Info

Model NO.：ZCC550H-1
Fixed Jib Length：6-15m
Traveling Speed：0-1.6km,H
Max. Gradeability：30%
Ground Pressure：0.068MPa
Deadweight：50.5t
Engine Model：Wp6g190e26
Rated Power：140kw
Transport Package：Container,RO-RO
Specification：12800*4600(3300)*3120 mm
Trademark：ZOOMLION
Origin：China
HS Code：8426491000
Production Capacity：100,Month

Description

Max. lifting capacity × radiust × m55×3.7 Max. lifting capacity on fixed jibt5.5 Max. lifting capacity of luffing jibt12 Main boom lengthm13 - 52 Fixed jib lengthm6 - 15 Max. length of main boom with fixed jibt43+15 Luffing jib lengthm16m-28m Max. main boom +max. luffing jibm40mm+28mm Derricking angle.30 - 80 Fixed jib angle.10,30 Max. rope speed
of winchesHoisting winch 1m/min125/100With optional free-fall functionHoisting winch 2125 Derricking winch80 Slewing speedrpm

0-2.1

Traveling speedkm/h0-1.6 Max. gradeability%30With basic boom and counterweight over frontGround pressureMpa0.068 Deadweightt50.5With basic boomCrane counterweightt17.5 Overall dimensions(L × W × H)m12800×4600(3300)×3120With A-frame and main boom pivot sectionEngineModel WP6G190E26Manufacturer:Weichai Power CO, Ltd.Rated power / rotational speedkW/r/min140/1900Max. output torque /rotational speedNm/r/min830/1300Exhaust emission National StageDistance between track center × crawler contact length × crawler widthmm2540 ×5000×760Crawler carrier retracted3840 ×5000×760Crawler carrier extended NoiseNoise level outside operator's cab during operation(dB)≤107 Noise level in operator's cab during operation≤85
