New Product Rt35 Hydraulic Suspension Rough Terrain Crane

Newindu Construction Engineering (Shanghai) Co., Ltd.

After-sales Service：Online Service
Warranty：One Warranty
Certification：CE, ISO9001
Condition：New
Maximum Lifting Height：>40m
Maximum Lifting Weight：>16t

Base Info

Model NO.：RT35
Shaft Number：3
Crane Jib：Five-Arm
Type：Straight Arm
Lateral Outrigger Span：6.9m
Max. Travel Speed：72km,H
Weight (Kg)：35000 Kg
Transport Package：Container Bulk Nude Frame
Specification：35000kg
Trademark：china top
Origin：China
HS Code：8705109200
Production Capacity：100pieces,Month

Description

TypeItemUnitValueWorking performanceMax. rated lifting weight × working radiuskg.m35000×3.0 Max. lifting moment of basic boomkN.m1344 Max.lifting moment of longest boomkN.m870 Max. lifting height of longest boomm31 Max. lifting height of jibm46DimensionsOutline dimensions (L×W×H)mm11935×2980×3600 Distance between outriggers (Longitudinal × transversal)mm6810×6800 Main boom length (completely retracted - completely extended)mm9800~31000 Jib length (completely retracted - completely extended)mm9088~15028 Main boom angle of elevation°-3~78 Swing range 360°continuouslyWorking speedMax.speed of single rope on the drum of main winchm/min150 Boom extension times70 Boom retraction times75 Boom derricking up times46 Boom derricking down times47 Swing speedr/min0~2.5Hydraulic systemRated working pressureMPa27 Rated working flowL/min400 Hydraulic oil tank capacityL600MassComplete vehicle kerb masskg32000 Front axle loadkg15030 Rear axle loadkg16970TravelingMax. traveling speed (forwards / backwards)km/h38/15 Wheelbasemm3820 Treads (front / rear)mm2444 Max. gradeability%57 Min. turning radius (outer edge of the vehicle body)m6.5 Min. turning radius (2 wheels)m11.25
