• Model NO.：ZTC251V451
• Type：Folding
• Max. Rated Lifting Capacity：25000kg
• Max. Lifting Height of Jib：46.58m
• Transport Package：Comply with Export Packaging Requirements for Min
• Specification：12700*2500*3450 mm
• Trademark：ZOOMLION
• Origin：China
• HS Code：84262000
• Production Capacity：100 Units Per Month

ItemValueRemarksWorking performance rated lifting capacitykg16000 load moment of basic boom980 kN.m load moment of boom lengthkN.m573 lifting height of basic boom m11.5  lifting height of boom m33.8

Deformation of the boom is

not taken into consideration.

 lifting height of jib m41.6Working speedhoist rope speed (main winch) m/min120At 4^th layer hoist rope speed(auxiliary winch) m/min100At 2^nd layerBoom derricking times40 Boom extending times60 Slewing speed r/min0~2.2 Traveling specifications traveling speed km/h78  gradeability %37 Min. turning diameter m≤22 Min. ground clearance mm220 Limits for exhaust pollutants and smokeMeet with related standardsGB3847-2005GB17691-2005(National stage III)Oil consumption per hundred kilometers L45
