• Model NO.：STC250
• Type：Folding
• Place of Origin：Hunan, China
• Lifting Capacity：25t
• Max.Lifting Height：48.1m
• Engine Rated Output(Kw/Rpm)：213,2200
• Max.Travel Speed：80km,H
• Overall Dimensions：12800mm*2500*4000mm
• Dead Weight in Travel State：30000kg
• Moving Type：Wheel
• Transport Package：Roro or Bulk Break Shipment
• Specification：CE
• Trademark：S ANY
• Origin：Hunan, China
• HS Code：87051091
• Production Capacity：100 Units Per Month

Parameter of STC250 25ton Truck CraneModelSTC250SLifting load(T)25TBoom43.5Lifting height (M)79mSwing radius360°Outrigger span12.2MFully
extendingMin working
radius(75°)5.176mMax working
radius(45°)43.5MDead weight in working25 tonsDimension12.85m * 2.50m * 3.65mEngine model4D*23-130E3Power typeDieselDisplacement/power(ml/KW)385795.5Emission standardGB17691-2005,GB3847-2005Dimension1285025003650Steel spring (pcs)6/12+4Speed of chassis (km/h)94.5Types8.25-16Tread (Front/Back) mm17601620Wheel base (mm)3815Axles5Cab (persons)3
=====================================================================================
Powerful Lifting Capacity
STC250 25 ton crane has four-section boom of high strength steel structure and optimized U-shaped cross section with max.lifting capacity of 25t, full-extended boom length of 33.5m, max.lifting height including jib of 42m, reduce weight and improve safety significantly.
Jib mounting angles are 0°, 15°, and 30°, which ensure fast and convenient change-over between different operating conditions so as to improve working efficiency of the machine.

Efficient & Unique Hydraulic System
Triple gear pump, load feedback and constant power control are applied to provide strong lifting capacity and good micro-mobility. Unique steering buffer design guarantees smooth braking operation.

Intelligent Electronic Control
Self-developed controller SYMC special for engineering machinery is configured. The adoption of CAN-bus full-digital network control technology ensures stable control signal, simple harness, and high reliability. Timely feedback of data information can achieve the monitoring of the overall working status in real time.

The Load Moment Limiter
Equipped with the comprehensive intelligent protection system is used with accuracy within 3%. The adoption of comprehensive logic and interlock control system ensures more safe and reliable operation.

More Safe Devices
Main and auxiliary winches are equipped with over roll-out limiter to prevent over rolling-out of wire rope.
Boom and jib ends are equipped with height limiters respectively to prevent over-hoisting of wire rope.
Hydraulic system is configured with the balance valve, overflow valve and two-way hydraulic lock etc., to ensure stable and reliable operation.
