• Model NO.：QRY70
• Type：Straight Arm
• Dead Weight：48800 Kg
• Max.Travel Speed：40km,H
• Max. Total Rated Lifting Load：70t
• Min.. Rated Working Radius：3m
• Outline Dimensions Length*Width*Height：12970*3350*3840mm
• Transport Package：Nude
• Specification：ISO9001: 2000
• Trademark：sinoheng
• Origin：Xuzhou, China
• Production Capacity：200PCS,Month

70t QRY70 Rough Terrain Crane Main technical specifications in travel configurationCategoryItemUnitSpecificationOutline Dimensions
 Overall lengthmm12970Overall widthmm3350Overall heightmm3840Axle basemm4650Tyre treadmm2350WeightDead weight in travel statekg48800Axle loadFront axlekg22560Rear axlekg26240Travel

 Max.travel speedkm/h40Min. turning radiusmm6500Min. turning radius for boom headmm12100Min. groud clearancemm530Approach angle°24.5Departure angle°24.5Max. gradeability%55PowerEngine rated outputKw/(r/min)228/2100Engine rated torqueN.m(r/min)1200/1000~1700Max. Travel speedr/min210070T Rough Terrain Crane Main technical specifications in lifting configurationCategoryItemUnitSpecificationspecificationsMax. total rated lifting loadt70Min.. rated working radiusm3Turning radius at swing table tailm4.7Max. Lift forceBase boomkN@m2502Fully extended boomkN@m987Outrigger distanceLongitudinalm7.75Lateralm                                         7.6Lifting heightBase boomm10.7Fully extended boomm36.75boom lengthBase boomm10.2Fully extended boomm37Jib offset angle          °0/30Working Speedelevating timeBoom raising times85Boom descending times85Boom Extend/ retract timeBoom fully extend times125Boom fully retracting times95Max.swing speedr/min2Outrigger Extend/retract timeOutrigger beamOutrigger beam extending sychronouslys30Outrigger beam retracting sychronouslys25Outrigger jackOutrigger beam extending sychronouslys35Outrigger beam retracting sychronouslys60Lifting speed(single rope)Main winchFull loadm/min120Empty loadm/min120Auxiliary winchFull loadm/min120Empty loadm/min120
