Crawler Crane 260 Tons Scc2600A Superior Condition Adaptability
Newindu Construction Engineering (Shanghai) Co., Ltd.- After-sales Service：Online Service
- Max. Lifting Height：One Warranty
- Rated Loading Capacity：5ton
- Certification：CE
- Condition：New
- Warranty：1 Year
Base Info
- Model NO.：SCC2600A
- Rated Loading Capacitys：5ton
- Engine Power：21.2kw
- Maximum Lifting Capacity *Radius：52m
- Transport Package：Bulk Cargo ,RO-RO
- Specification：5ton
- Trademark：china top
- Origin：China
- HS Code：8426200000
- Production Capacity：100pieces,Month
Description
Model
SCC2600A
Boom Operating Condition
Maximum rated hoisting capacity
260t
Boom length
13~52m
Boom luffing angle
30~80°
Maximum rated lifting torque
203t.m
Fixed jib Operating Condition
Longest boom+longest jib
43+15.25m
Fixed jib offest angle
10°
Working Speed
Wire speed of main and auxiliary hoist
0~110m/min
Wire speed of luffing hoist
0~62m/min
Swing speed
0~3.2rpm
Traveling speed
0~1.39rpm
Engine
Output power/Rated speed
132/2200 kw/rpm
Transportation Parameters
Max.transport weight of single piece
29.5t
Transport dimension(L*W*H)
7160×3360×3260mm
Other Parameters
Average ground pressure
0.059MPa
