• Model NO.：Xca1200
• Type：All Terrain Crane
• Overall Length：19695mm
• Overall Width：3000mm
• Overall Height：4000mm
• Dead Weight in Travel State：83600kg
• Max. Travel Speed：80km,H
• Max. Grade Ability：Greater-Than Sign 58%
• Transport Package：Comply with Export Packaging Requirements
• Specification：ISO
• Trademark：XCMG
• Origin：Xuzhou, Jiangsu, China
• HS Code：87051023
• Production Capacity：10000,Year

Overview CategoryItemUnitParameter

Outline DimensionsOverall (length×width×height)mm19695×3000×4000Wheel basemm1600/2350/2135/1650/2950
/1600/2950Track(Front/Rear)mm2540/2540Front overhang/rear overhangmm2780/1678Front extension/rear extensionmm0


WeightMax. allowable total masskg83600

Axle load1st and 2nd axleskg9000/90003rd and 4th axleskg9000/9000/90005th and 6th axleskg11900/119007th and 8th axleskg11900/11900








Power


Superstructure engineModel OM460LA.E3A/5Rated power/rotation speed
kw/(r/min)
260/1800Rated torque/rotation speed
N.m/(r/min)
1750/1300



Chassis engineModel OM502LA.E3B/1OM502LA.E3A/1Rated power/rotation speed
kw/(r/min)
482.2/1800
480/1800Max. net power/rotation speed
kw/(r/min)
480/1800
480/1800Max.output torque/rotation speed
N.m/(r/min)
3000/1300
2800/1300

Travel Performance
Travel speedMax. travel speedkm/h≥80Min. steady travel speedkm/h≤2.4Min. turning diameterm≤27Min. ground clearancemm382

 Product Show



 Company Profile

FAQ

1: What kind terms of payment can be accepted?
A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted

2: What certificates are available in Machinery?
A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC,

3: What about the delivery time?
A: 30 days after receiving the deposit.

4: What about the warranty time?
A: 12 months after shipment or 2000 working hours, whichever occuts first.

5. What about the Minimum Order Quantity?
A: The MOQ is 1 pcs.
