China High Quality 80ton Mobile Crane Truck
Uptra Electric & Machinery (Shanghai) Co., Ltd.- Certification：GS, RoHS, CE, ISO9001
- Condition：New
- Maximum Lifting Height：>40m
- Maximum Lifting Weight：80ton
- Shaft Number：3
- Crane Jib：Five-Arm
Base Info
- Model NO.：hydraulic truck crane
- Type：Folding
- Overall Dimension：14770X2800X3890mm
- Wheel Base：2380+2075mm
- Track：2074,1834,1834mm
- Max. Travel Speed：80km,H
- Min. Travel Speed：3km,H
- Min. Turning Diameter：24m
- Min. Ground Clearance：371mm
- Max. Grade Ability：40%
- Application：Construction Lifting
- Engine Rated Power：290,1900kw,(R,Min)
- Engine Rated Torque：1900,1000-1400n.M,(R,Min)
- Approach Angle：17degree
- Departure Angle：15.5degree
- Braking Distance：Less Than10m
- Max. Total Rated Lifting Capacity：80t
- Transport Package：Nacked
- Specification：CE
- Trademark：Super-above
- Origin：Jiangsu, China
- HS Code：8705109100
- Production Capacity：10000PCS,Year
Description
DescriptionUnitParameter valueOverall lengthmm14770Overall widthmm2800Overall Heightmm3890Axle base1st ,2nd axlemm14702nd ,3rd axle40003rd ,4th axle1350Wheel Basemm 2380+2075Total vehicle mass in travel configurationkg50000Axle load 1st and 2nd Axlekg240003rd and 4th Axle26000Engine Model WP12.375NMC11.39-30Engine rated powerkw/(r/min)276/1900290/1900Engine rated torqueN.m/(r/min)1800/1000-14001900/1000-1400Max. travel speedkm/h80Min. steady travel speedkm/h3Min. turning diameterm24Min. turning diameter at boom tipm29Min. ground clearancemm371Max. grade ability%40Approach angle°17Departure angle°15.5Braking distance (at 30 km/h, full load )m≤10Oil consumption per 100kmL45
