70t Heavy Lifting Truck Crane Qy70k-I

Evangel Industrial (Shanghai) Co., Ltd.
  • After-sales Service：Free Spare Parts
  • Warranty：One Year
  • Certification：GS, RoHS, CE, ISO9001
  • Condition：New
  • Maximum Lifting Height：>40m
  • Maximum Lifting Weight：>16t

Base Info

  • Model NO.：QY70K-I
  • Shaft Number：4
  • Crane Jib：Five-Arm
  • Type：Folding
  • Feature：Truck Crane
  • Rated Loading Capacity：70ton
  • Rated Lifting Moment：2303kn.M
  • Max. Lifting Load：70ton
  • Max. Lifting Height：59.5m
  • Span：7.1m
  • Model Number：Qy70k-I
  • Transport Package：Seaworthy Packing: Roro
  • Specification：CE,ISO
  • Origin：Jiangsu, China
  • HS Code：87051092
  • Production Capacity：100 PCS,Month

Description

DimensionUnitQY70K-IOverall lengthmm13930Overall widthmm2800Overall heightmm3575Weight  Total weight in travelkg43000(without 1t vice counterweight)Front axle loadkg17000Rear axle loadkg26000Power  Engine model WD615.338(domestic III)Engine rated powerkW/(r/min)276/2200Engine rated torqueN.m/(r/min)1500/1400Travel  Max. travel speedkm/h80Min. turning diameterm24Min. ground clearancemm327Approach angle°19Departure angle°13Max. grade ability%40Fuel consumption for 100kmL45Main performance  Max. rated total lifting capacityt70Min. rated working radiusm3000Turning radius at turntable tailm3.55Max. lifting torquekN.m2303Base boomm11.6Fully extended boomm44.5Fully extended boom+ jibm59.5Longitudinal outrigger spanm6.1Lateral outrigger spanm7.3Working speed  Boom luffing times60Boom full extension times≤150Max. swing speedr/min≥2.0Max. speed of main winch (single rope) (no load)m/min≥130Max. speed of aux. winch (single rope) (no load)m/min≥108
