• Model NO.：QY50KA
• Crane Jib：Five-Arm
• Type：Straight Arm
• Hydraulic Cylinder Brand：Undetermined
• Rated Loading Capacity：50t
• Feature：Truck Crane
• Rated Lifting Moment：1822kn.M
• Unique Selling Point：Long Lifetime
• After-Sales Service Provided：Video Technical Support, Online Support
• Hydraulic Valve Brand：Undetermined
• Application：Construction
• Max. Lifting Height：57.7m
• Hydraulic Pump Brand：Undetermined
• Engine Brand：Sinotruck
• Span：6.9m
• Transport Package：Standard
• Specification：13930*2780*3630mm
• Trademark：XCMG
• Origin：Jiangsu, China
• Production Capacity：10000 Unit,Units Per Month

Overview Product Parameters



DescriptionUnitParameter valueOverall lengthmm13930Overall widthmm2780Overall Heightmm3630Axle base1st ,2nd axlemm14702nd ,3rd axle43003rd ,4th axle1350Wheel Basemm2304+2075Front overhang/rear overhangmm2389/2064or 2376/2064Front extension/rear extensionmm2131/226 or 2144/226Total vehicle mass in travel configurationkg42200Axle loadFront axlekg16200Rear axle26000Engine Model WD615.338Engine rated powerkw/(r/min)276/2200Engine rated torqueN.m/(r/min)1500/1300-1600Max. travel speedkm/h85Min. steady travel speedkm/h2~3Min. turning diameterm24Min. ground clearancemm327Max. grade ability%42Approach angle°19Departure angle°15Braking distance (at 30 km/h, full load )m≤10Oil consumption per 100kmL40Exterior noise level during acceleration travelingdB (A)≤88Noise level at seated positiondB (A)≤90Detailed PhotosOur Advantages
